  • Page 1 Model VR59**L/VR59**L* Language English Page Color(cover/body) Weight 80g 190×260(mm) 12.11.02 Date Designer Ma Yongli Part No Owners Manual MFL67086053 Description Chage Record Change content Designer Confirm ECO No.
  • Page 2 OWNER’S MANUAL HOM-BOT Before using, please carefully read the Safety Precautions pages to allow for safe operation of the product. After reading the operation manual, please keep it in an easily accessible location. VR59**L VR59**L* www.lg.com...
  • Page 3 FEATURES Images of the floor are obtained from the sensors of the lower camera, and through this, the location of HOM-BOT will be confirmed,therefore, elaborate cleaning can be accomplished for every part of the room. Camera sensor As the height of the HOM-BOT is low (90mm), even the underside of a framed bed or furniture can be cleaned.

  • Page 4: Table Of Contents

    CONTENTS BEFORE USING ADDITIONAL INFORMATION Safety Precautions 26~28 Troubleshooting Included with Product Before You Call for Service Parts Descriptions Button Functions REFERENCE Display Status Information Product Specifications Before You Start Overview HOW TO USE How to Install the Home Station How to Turn the Power Supply On and Off.
  • Page 5 If the supply cord is damaged, it must be replaced by LG Electronics Service Agent in order to avoid a hazard. This appliance can be used by children aged from 8 years and above and persons with reduced physical,...
  • Page 6 Failure to follow this warning can cause fire or Doing so can cause fire or product failure. product failure. If the power cord is broken, replace it at an LG Electronics customer care center. Do not place the home station and Always use a dedicated outlet.
  • Page 7 SAFETY PRECAUTIONS WARNING Do not spray or suck in inflammable Turn the power supply off immediately if materials, surfactants, or drinking wa- any abnormal sound, odor, or smoke is ter in the vicinity of the HOM-BOT. generated from the HOM-BOT. Failure to do so can cause fire or product Doing so can cause fire or product failure.
  • Page 8 Doing so can cause product failure. put any water or detergent on the HOM-BOT. If liquids get inside of the HOM-BOT, turn off the power supply and contact an LG Electron- ics sales agent or customer care center. When the robot cleaner is operat- If the floor is wet or has wet spots,...
  • Page 9 HOM-BOT...

  • Page 10: Parts Descriptions

    PARTS DESCRIPTION Top view Dust bin cover button Dust bin cover Status indication lamp Detecting sensor of home station & receiving sensor of remote controller Front view Ultrasonic sensor Rear view Ventilation port Bottom view Cliff detection sensor Charging terminal Brush Side brush Wheel...
  • Page 11 PART DESCRIPTION – HOME STATION / DUST BIN Home station Power lamp Charging terminal Reset button Power cord fixing groove Dust bin Dust bin handle Dust bin cover Suction port cover Sponge filter Dust bin cover opening HEPA filter button Figures can be different from actual objects.

  • Page 12: Button Functions

    BUTTON FUNCTIONS Pres START/ST HOM-BOT s r /s Pres START/ST HOM-BOT START/ST ress HOM-BOT START/STOP Pres START/ST w se HOM-BOT. HOM-BOT ressed...
  • Page 13 BUTTON FUNCTIONS – REMOTE CONTROL Start Charging The HOM-BOT will start cleaning The HOM-BOT will move to the home station for charging. Directional button Stop The HOM-BOT will move as desired If the HOM-BOT is in operation it will by the user: to front, rear, left, and be stopped.

  • Page 14: Display Status Information

    DISPLAY STATUS INFORMATION Battery and reserved time indi- cation evel own. ese va own. Timer icon ca es Battery icon T canc START/ST HOM-BOT.

  • Page 15: Before You Start

    BEFORE YOU START Check these items before cleaning ot use this device in a room where a child is left alone. The child could be injured. Remove fragile or unnecessary objects from the room to be cleaned. Especially, remove expensive ceramics and valuables from the floor. Remove any moisture that might be on the floor.

  • Page 16: Overview

    OVERVIEW Install the home station. (page 13) 1.5m Insert the power cord plug into an outlet and locate the station against a wall. If power is not supplied to the 1.5m home station, the HOM-BOT will not charge. Turn on the power supply of the HOM-BOT. (page 14) Turn on the power switch located on the bottom of the Roboking and press the upper START/STOP button to turn on the power supply.

  • Page 17: How To Install The Home Station

    Do not operate the HOM-BOT if it has a damaged cord or plug, if it is not working properly, or if it has been damaged or dropped. To avoid hazard, the cord must be replaced by LG Elec- tronics, Inc. or a qualified service person.

  • Page 18: How To Turn The Power Supply On And Off

    HOW TO TURN THE POWER SUPPLY ON AND OFF. Turning on the main power supply To turn the power supply on, turn the HOM-BOT upside down on a smooth/soft surface and check whether the main power sup- ply switch is turned on. If the main power supply switch is turned off, turn on the switch.

  • Page 19: 5 How To Start And Stop Cleaning 16~17

    HOW TO START AND STOP CLEANING Using the buttons on the HOM-BOT After the HOM-BOT is turned on, press the START/STOP button to begin cleaning. A melody will sound and cleaning will begin. Press the START/STOP button during the cleaning cycle to stop cleaning. When the ‘START/STOP’...

  • Page 20: How To Charge The Battery

    HOW TO CHARGE THE BATTERY Automatic charging The HOM-BOT returns to the home station at the end of a cleaning cycle or when its battery is running low. If the HOM-BOT is unable to dock to the home station on its first at - tempt, it will try again until it docks successfully.
  • Page 21 HOW TO CHARGE THE BATTERY Remaining Battery Charge Indicator The remaining battery charge can be confirmed from the charge indication light, which will indicate charge as follows: During charging, the charge remaining indication light will flicker. When charging is completed at the home station, only the battery icon will illuminate to save power. The battery icon will flicker when battery charging is required.

  • Page 22: Cleaning Modes

    CLEANING MODES Spatial expansion cleaning When the START button on the main unit or the remote control is pressed, HOM-BOT operates in the spatial ex- pansion cleaning mode. The 1st stage: A maximum area of 3 m x 3 m (9.84 ft x 9.84 ft) will be cleaned.

  • Page 23: Auxiliary Cleaning Modes

    AUXILIARY CLEANING MODES Manual cleaning This method of cleaning involves manually moving the HOM-BOT by pressing the directional (arrow) buttons on the remote control. The interior space will be cleaned by the HOM-BOT as it is being moved to the front, rear, or rotated to the left and right side according to the input of the directional buttons.

  • Page 24: Timer Cleaning

    TIMER CLEANING HOM-BOT can be scheduled to start cleaning after a certain period of time. The time can be set among 2 hours, 6 hours and 12 hours. 1. By pressing the TIMER button on the re- mote control or the HOM-BOT, a clean- ing time can be scheduled.

  • Page 25: Cleaning The Dust Bin

    CLEANING THE DUST BIN If the dust bin is full, suction power can be weakened. Clean the dust bin before and after each cleaning ses- sion. Clean the dust bin using the following sequence: 1. Open the dust bin cover by pressing the PUSH button on the HOM-BOT.

  • Page 26: Cleaning The Dust Bin Filter

    CLEANING THE DUST BIN FILTER The dust bin filters are comprised of the HEPA filter and the sponge filter. Clean the HEPA filter and the sponge filter according to the following sequence: 1. Separate the HEPA filter and the inside sponge filter by removing the HEPA filter.

  • Page 27: Cleaning The Brush

    CLEANING THE BRUSH The brush, located on the bottom of the HOM-BOT, helps with the suction of foreign objects. Perform the fol- lowing steps to clean the brush: Lay a smooth cloth on the floor. Separate the cover by press- Wearing gloves turn the brush Turn the HOM-BOT over and ing the fixing hook and pulling...

  • Page 28: Cleaning The Sensor/Charging Terminal

    CLEANING THE SENSOR/CHARGING TERMINAL There are sensors on the HOM-BOT that can detect obstacles, stairways and the home station for charging the battery. In order to maintain the performance of the HOM-BOT, regularly clean the sensors and charging terminal as follows: 1.

  • Page 29: Cleaning The Side Brush

    CLEANING THE SIDE BRUSH Foreign objects/materials such as hair can easily adhere to the side brush. Remove such materials at least once a week. If excessive amounts of foreign materials are stuck to the brush, there is the risk of breakage. If the floor is rough or walls are frequently cleaned, the side brush may bend or become damaged.
  • Page 30 TROUBLESHOOTING When the voice, “Please check the wheels”, is announced. If the unit becomes stuck or suspended and the wheels do not allow the unit to move, the voice, “Please check the wheels”, will be announced. wheel trapped in the front door, balcony, stairway, etc? Move the HOM-BOT on to the flat floor.
  • Page 31 TROUBLESHOOTING When the voice, “Please check the dust bin”, is announced When an abnormality is detected with the dust bin, the voice, “Please check the dust bin”, is announced. st bin fitted correctly? Open the dust bin cover, and if check if the dust bin is actually fitted. the unit will not operate without the dust bin.
  • Page 32 TROUBLESHOOTING When the voice, “Please check the brush”, is announced. When the HOM-BOT detects that the brush is not functioning properly, you will hear the message “Please check the brush. ” Lay a smooth cloth on the floor, overturn the HOM-BOT, and place it on the cloth. The side brush is stuck.
  • Page 33 BEFORE YOU CALL FOR SERVICE Check the following before calling for service. Problem Solutions (Reference page) The HOM-BOT will not activate. Confirm that the battery has been charged. (page 17) Carefully wipe the sensor with a smooth cloth. (page 24) Movements or travel path are abnormal.
  • Page 34 PRODUCT SPECIFICATIONS Item/model LG HOM-BOT VR59**L VR59**L* External dimension Φ 360 mm X 90 mm Weight 3.2 kg Power consumption 15 W Battery (fully charging) DC 16.8 V Traveling velocity 350 mm/sec Use time Approx. 90 minutes (1 time charging) Based on general floor surface...
  • Page 35 MEMO...
