FEATURES
Corner Master
By having adopted a brand new concept design that is appropriate for walls,
the Robot Cleaner's cleaning performance is incredibly ef cient.
Learning Mode
The Robot Cleaner is capable of memorizing the cleaning environment
via its Smart Operation feature for smarter cleaning.
Turbo Mode
In the Turbo mode, the Robot Cleaner operates the suction motor and the brushes
at a greater speed giving cleaner results.
Drawer Mop Plate (Selected models only (VR*.LVM))
The "Drawer mop plate" makes it much easier for users to t and remove the mop
without having to turn over the device over.
My Space Mode
By commanding it to clean a particular area, the Robot Cleaner quickly cleans
that desired area.
Repeat Cleaning
The Robot Cleaner will continuously clean until the battery runs out.
Location Search Function
If the Robot Cleaner is moved from a spot while operating, the device will automatically
search for the previous location and return to the spot from where it was interrupted.
Advertisement
Table of Contents
Related Manuals for LG VR34406LV
Summary of Contents for LG VR34406LV
- Page 1 FEATURES Corner Master By having adopted a brand new concept design that is appropriate for walls, the Robot Cleaner's cleaning performance is incredibly ef cient. Learning Mode The Robot Cleaner is capable of memorizing the cleaning environment via its Smart Operation feature for smarter cleaning. Turbo Mode In the Turbo mode, the Robot Cleaner operates the suction motor and the brushes at a greater speed giving cleaner results.
-
Page 2: Included With Product
INCLUDED WITH PRODUCT Robot Cleaner Remote controller Home station Figures can be different from actual objects. Cleaning Tool Dust bin filter (spare) DVD Manual (Optional) Mop plate Ultra microfiber mop (2 pieces) (Selected models only (VR*.LVM)) (Selected models only (VR*.LVM)) for cleaning sensors for cleaning... - Page 3 PARTS DESCRIPTION - ROBOT CLEANER Plan view Upper camera sensor Dust bin cover Display & function buttons Dust bin compartment release button Front view Ultrasonic sensors Obstacle detecting sensor window Detecting sensors of home station & Receiving sensors of remote controller Rear view Main Power switch Ventilation port...
- Page 4 PARTS DESCRIPTION – HOME STATION / DUST BIN Home station Remote controller holder Charging terminals Power switch Power cord fixing hook Dust bin Dust bin handle Cleaning brush Dust bin lid Suction port flap Sponge filter Dust bin lid opening button HEPA filter Filter cover Figures can be different from actual objects.
- Page 5 BUTTON FUNCTIONS – ROBOT CLEANER • If the button is pressed, ‘TURBO Mode’ will be set with a voice confirmation. TURBO • If the button is pressed whilst in ‘TURBO Mode’ , it will be canceled. • Used to turn the power on from Standby, start or stop cleaning. •...
- Page 6 BUTTON FUNCTIONS – REMOTE CONTROLLER Start Home Pressing this button will start Used to recharge the Robot Cleaner by the cleaning. (p16) making it return to the Home Station. (p17) Mode Turbo Change the Cleaning Mode of Used to activate or deactivate Robot Cleaner to ZigZag Mode.
-
Page 7: Display Status Information
DISPLAY STATUS INFORMATION Turbo Mode icon Operational Status icon Homing icon This indicates the settings This indicates the operational This indicates the conditions for Turbo Mode. status of Robot Cleaner. of Homing and Charging. Repeat Mode icon Mute icon This indicates the settings This indicates the settings for Repeat Mode. -
Page 8: Before You Start
BEFORE YOU START Check these items before cleaning • Do not use this device in a room where a child is left alone. The child could be injured. • Remove fragile or unnecessary objects from the room to be cleaned. Especially, remove expensive ceramics and valuables from the floor. - Page 9 OVERVIEW Install the home station. (p14) 1.5 Insert the power cord plug into an outlet and locate the station 2 against a wall. If power is not supplied to the home station, the 1.5 Robot Cleaner will not charge. Turn on the power supply of the Robot Cleaner.
-
Page 10: How To Install The Home Station
Do not operate the Robot Cleaner if the Home Station has a damaged cord or plug, if it is not working properly, or if it has been damaged or dropped. To avoid electrical hazards, the cord must be replaced by LG Electronics, Inc. or a qualified service person. -
Page 11: Turning On The Main Power Supply
HOW TO TURN THE ROBOT CLEANER POWER SUPPLY ON & OFF Turning on the main power supply Make sure the Power Switch is on at the rear-left of the Robot Cleaner. If the power is OFF, turn the switch ON. ※... -
Page 12: How To Start And Stop Cleaning
HOW TO START AND STOP CLEANING Using the buttons on the Robot Cleaner After the Robot Cleaner main power switch is turned on, press the START/STOP button to begin cleaning. A melody will sound and cleaning will begin. Press the START/STOP button during the cleaning cycle to stop cleaning. ※... -
Page 13: How To Charge The Battery
HOW TO CHARGE THE BATTERY Automatic charging The Robot Cleaner returns to the home station at the end of a cleaning cycle or when its battery is running low. ※ If 10 minutes elapse without the Robot Cleaner moving or the battery is too low, the power will be automatically turned OFF. -
Page 14: Cleaning Modes
CLEANING MODES Zigzag Cleaning In 'Zigzag' mode, Robot Cleaner repeats a zigzag operation to clean each and every spot in the cleaning area. If you need to quickly clean an area choose 'Zigzag' mode. Press ‘Mode’ button on Remote Controller to select 'Zigzag' mode and press 'Start' button. - Page 15 CLEANING MODES My Space Cleaning Pressing 'My Space' on the Remote Controller will set the My Space cleaning mode with a voice message. For cleaning of particular spaces, select this mode. The 1st stage: Use the Remote Controller to manually set the parrameters of each cleaning block. ※...
-
Page 16: Auxiliary Cleaning Modes
AUXILIARY CLEANING MODES Turbo Mode Pressing the 'Turbo' button on the Remote Controller or main unit will activate 'Turbo' mode, with a voice message. While in 'Turbo' mode, pressing the same button will cancel 'Turbo' mode, with a voice message. In 'Turbo' mode, Robot Cleaner runs more intensely for a powerful clean. - Page 17 MOP CLEANING (Selected models only (VR*.LVM)) By attaching the ultra micro ber mop, you can effectively use the Robot Cleaner to remove dust on hard oor surfaces. When the mop plate is attached, the Robot Cleaner will not climb on to carpets or over thresholds, in order to prevent transferring dirt from the mop.
-
Page 18: Location Search Function
LOCATION SEARCH FUNCTION The Robot Cleaner remembers its location while cleaning. If the user moves the Robot Cleaner while it is operating, it will search for the location it was moved from by using its navigational location search function before continuing to clean. ※...
