Specifications - Fender concert-reverb Service Manual

Product Release No.:
Part Number:
Power Requirements:
Power Amp Section:
Power Output:
Input impedance:
Tubes:
Fuses:
Speaker Complement:
Footswitch:
Dimensions:
Weight:
CONCERT-REVERB AMP

SPECIFICATIONS

PR 450 (This is not a model number)
120V Version :
240V Aus
230V UK
230V Eur
100V
325W
50 Watts RMS (High Output)
12.5 W RMS (Low Output)
1kHz sine wave into 8Ω @<5% THD (Presence @ "1")
1MΩ
Two 6L6GC (P/N 053980)
Two 12AX7A (P/N 023572)
Five 12AX7WA (P/N 013341)
One 12AT7 (P/N 023531)
F200: F3A 250V (100V, 120V units)
T2A 250V (230V, 240V units)
F201: T5A 250V (Internal filament fuse on 230V, 240V units)
F1 & F2: T100mA 250V (all units)
Four 8 Ω Fender 10" (P/N 048832)
Four-Button: Channel, Effects, Reverb, Tremolo (P/N 057025)
Height:25 3/4"
Width: 25 3/8"
Depth: 12 27/32"
85 lbs.
Product specifications are subject to change without notice
21-5900
: 21-5930
: 21-5940
: 21-5960
: 21-5970
(65.7 cm)
(64.7 cm)
(32.8 cm)
(38.6 kg)
