Chassis Assy; Cabinet Assy; End Item - Fender concert-reverb Service Manual

QTY PART #
1 0027846000
1 0032524000
2 0019279000
4 0026571000
16 0027199000
20 0021972000
4 0022244000
4 0026625000
REF 0029086000
REF 0029085000
REF 0026570000
REF 0037350000
REF 0037788000
QTY PART #
1 0056525000
1 0057060000
REF 0057224000
REF 0057062000
REF 0057063000
1 0047248000
REF 0047251000
REF 0047249000
REF 0047250000
REF 0053997000
2 0024851000
2 0021998000
2 0022277000
2 0022285000
6 0022319000
2 0031344000
2 0024646000
2 0024752000
4 0057105000
6 0029527000
6 0036199000
1 0023192000
3 0037985000
1 0057025000
6 0057170000
2 0057171000
CONCERT-REVERB AMP
CABINET ASSEMBLY (cont)
DESCRIPTION
HANDLE 9.25" NO LOGO
INSERT HANDLE
HANDLE CAP 2 HOLE NICKEL
SCRW SMAB 8x5/8 THP NI
SCRW SMAB 10 X 3/4 PHP NI
NUT T 10-32x3/4 STR 3 PRNG BLX
SCRW M10-32 x 1 1/8 OHP NI
SCRW WOOD 8x1 FH
VELCRO STRIP HOOK 1.5"wd BLK
VELCRO STRIP LOOP 1.5"wd BLK
TOLEX "BRAVURA BLACK"
TAPE ALUM 8"X60YDS
CLOTH GRILLE BLACK/SILVER
END ITEM ASSEMBLY
DESCRIPTION
CABINET ASSY CONCERT REVERB
CHASSIS ASSY. CONCERT REVERB 120V DOM
CHASSIS ASSY. CONCERT REVERB 230V UK
CHASSIS ASSY. CONCERT REVERB 240V AUS
CHASSIS ASSY. CONCERT REVERB 100V JAP
CORD PWR W/IEC CONN DOM
CORD PWR W/IEC CONN 230V EUR
CORD PWR W/IEC CONN 230V UK
CORD PWR W/IEC CONN 240V AUS
CORD PWR W/IEC CONN 100V JPN
LEG AMP TILT 19
NUT FLEX LOCK 10-32 W/NYLON IN
SCRW M 10-32x1-1/2 OHP NI
WSHR SP LOCK 1/4x.493 ZI
WSHR FLAT 1/4x9/16 NI
SCRW SMA 10x3/4 OHP NI
WASHER LEG STOP TN
STRAP CHASSIS 4-1/2" NICKEL
SCRW M 8-32x1-3/16 OHP NI CP
WSHR FNSH 8-5/8 FLNGD BLX WX
SCRW M 8-32x1-3/16 OHP BLX CP
NAMEPLATE FNDR 65 TWIN
SCRW SMA 2x3/8 PHP BLX
FOOTSWITCH ASSY 4 BUTTON
CORNER SET 1 FOAM PRO-TUBE AMPS
CORNER SET 2 FOAM PRO-TUBE AMPS
REFERENCE DESIGNATION
REFERENCE DESIGNATION
@ CAB SIDES
@ TILTBACK LEGS
@ TILTBACK LEGS
@ TILTBACK LEGS
@ TILTBACK LEGS
@ TILTBACK LEG STOPS
@ CAB SIDES
CHASSIS TO CAB
Q.S.N. QUOTE QTY=1000
CHASSIS TO CAB
CHASSIS TO CAB
@ GRILLE FRAME
@ LOGO
