  • Page 1 Telestart T91...
  • Page 2 Deutsch Svenska English Norsk Français Suomi Italiano Polski Česky Español Nederlands Német Русский Dansk...
  • Page 3 We are delighted that you have selected this Webasto product. We assume that the workshop / service partner that carried out the installation explained to you the operation and principle of functioning of your Telestart T91 to your complete satisfaction.

  • Page 4: Care And Handling

    In enclosed rooms (e.g. garages), not even via the timer or Telestart. Care and handling Note the following points to avoid damage to the Telestart T91: Do not expose to heat above 70 °C (e.g. direct sunlight). Operating temperature between 0 °C and +50 °C.
  • Page 5 Using the Webasto Telestart T91, you can switch Webasto heaters (Thermo Top E, Thermo Top C, Thermo Top P, Thermo Top V) or the vehicle fan on and off at a long distance via a wireless link. To switch on the parking ventilation*(ventilation of the interior of the vehicle), the mode has to be changed on the transmitter.
  • Page 6 Optimum signal transmission is achieved out in the open or from a position higher than the vehicle.In this case, the auxiliary heating system can be operated at a distance of approx. 1000 m from the vehicle. When operating the transmitter, please hold it vertically pointing upward and do not cover the upper side (see photo).

  • Page 7: Programming Telestart Transmitter

    Programming Telestart Transmitter 1. Place batteries into the battery compartment of the transmitter. 2. Remove fuse 1A (black) from the heater's fuse holder (voltage interruption). 3. Wait at least 5 seconds. 4. Replace fuse in heater's fuse holder and within 5 seconds press the OFF-button on the transmitter for at least 1 second.

  • Page 8: Checking Mode

    Checking Mode Simultaneously depress and hold down the ON- and OFF-buttons. LED illuminates: = heating mode green = ventilating mode* LED extinguishes: – when the buttons are released, or – after 10 seconds *The “parking ventilation“ function is not available with upgrade of auxiliary heaters.

  • Page 9: Feedback From Transmitter Upon Turning On/Off

    Feedback from transmitter upon turning on/off The LED on the transmitter The signal has been received and the heater / lights up for 2 seconds: vehicle fan switched on or off. = heating mode green = ventilation mode The LED on the transmitter Error during signal transmission.

  • Page 10: Switching Off Heater Or Ventilation

    NOTE: In the 'heating' mode, the vehicle's heating system is to be set to "warm" prior to leaving the vehicle. In the 'heating' and 'ventilation' modes*, the vehicle's fan switch is to be turned to position 1 in the case of 3-speed blower fans, and to position 2 in the case of 4-speed blowers.

  • Page 11: Switching On/Off Using Pushbutton Switch

    NOTE: When the digital timer is used for activating the heater, the operating mode (parking heating or parking ventilation) most recently used with Telestart T91 will be selected.The operating duration, however, is governed by the digital timer. Switching off using a digital timer If the heater was activated using Telestart, the 'instant heat' must be pressed twice to deactivate the heater.

  • Page 12: Checking And Setting Operating Time

    Checking and Setting Operating Time The operating time of the heater or the vehicle's fan can be preset on the transmitter in increments of 10 minutes.The operating time is factory-set at 30 minutes. NOTE: We recommend setting the heating time according to the drive time. Example: The vehicle is used for travelling to work and back.

  • Page 13: Checking Operating Time

    Checking Operating Time Simultaneously actuate the ON- and OFF buttons within one second three times in succession. NOTE: The first coded flashing signal that is emitted immediately upon the third actuation of both buttons has to be included into the count. The LED flashes in accordance with the preset operating time.

  • Page 14: Setting The Operating Time

    Setting the Operating Time Press the OFF button to call up the next operating time. To store the setting: – do not actuate any button for 10 seconds, or – actuate the ON button. Returning to Default Setting Press the ON- and OFF buttons simultaneously for approx.

  • Page 15: Checking Battery

    Checking Battery Press the ON- or OFF button. Battery Action almost flashes orange for replace battery as spent 5 seconds soon as possible or warm up transmitter discharged lights up for replace battery 5 seconds in orange...
  • Page 16 Battery change See also page 19, "Programming Telestart Transmitter". Note Return batteries of our products after use at the point of purchase or in its immediate vicinity. Returning them is free. As end user you are legally obliged to return used batteries. Caution! Risk of explosion if battery is replaced by an incorrect type! Dispose of the used batteries...
  • Page 17 I tilfælde af en flersproget udgave er den tyske version gældende. Om det förekommer en flerspråkig version är den Webasto AG tyska bindande. Kraillinger Straße 5 Hvis det finnes en flerspråklig versjon, er det den tyske som har forrang.
