- Page 1 Installation Instructions ThermoCall TC4 Entry/Advanced...
- Page 2 Thermo Call TC4 # 24990A 965 082 AMP # 98393A # 67769A...
- Page 3 Thermo Call TC4 ThermoCall TC4 Entry 1 2 3 4 5 6 7 8 9 10 11 12 Please refer to the corresponding heater documentation for all other heater integrations.
- Page 4 Thermo Call TC4 ThermoCall TC4 Advanced 1 2 3 4 5 6 7 8 9 10 11 12 Please refer to the corresponding heater documentation for all other heater integrations.
- Page 5 Only genuine Webasto parts may be used. See also Webasto air and water heaters accessories catalogue. NEVER try to install or repair Webasto heating or cooling systems if you have not completed a Webasto training course, you do not have the necessary...
-
Page 6: Table Of Contents
Installation Instructions ............................1 General information .................................1 Certification ..................................1 Scope of Delivery Entry ..............................1 Scope of Delivery Advanced .............................2 Adapting wiring harness ..............................2 ThermoCall TC4 Entry: ..............................2 ThermoCall TC4 Advanced: ............................2 Legend ....................................2 SIM card ..................................3 Installation ................................4 Installing GSM module ..............................4 Installing GSM antenna ..............................4... -
Page 7: Installation Instructions
ThermoCall TC4 Installation Instructions General information Certification Scope of Delivery Entry With ThermoCall TC4 the following The CE marking and the E-marking GSM module ThermoCall TC4 are located on the adhesive label on Webasto heaters can be operated Entry wiring harness the module. -
Page 8: Scope Of Delivery Advanced
ThermoCall TC4 Scope of Delivery Advanced Adapting wiring harness Legend The included wiring harness must be To illustrations 1 to 6. GSM module ThermoCall TC4 adjusted with corresponding brown Advanced wiring harness "pinning into" the existing GSM antenna yellow installation situation (heater... -
Page 9: Sim Card
ThermoCall TC4 SIM card Only insert or remove the SIM card in the deenergised state. A SIM card not included in the delivery scope is required to operate The range is dependent on the the unit. respective network operator. Costs result from the operation of a SIM Both 1.8 V and 3 V SIM cards of a... -
Page 10: Installation
ThermoCall TC4 Installation Installing GSM module Installing GSM antenna Installing button with indicator lamp The GSM module must be installed in The antenna must be installed on the front or rear window. However, the passenger compartment. NOTE never in the tinted area or under the... -
Page 11: Connection
ThermoCall TC4 Connection Connector assignment of GSM module Socket Function Remarks Entry Advanced 12 - 24 V (+30) Earth = 0 Output of parking heater only for Thermo Top E/C additional analogue output, 12-24 V positive *... -
Page 12: Connection Of An Alarm System Installed In The Vehicle (Advanced)
ThermoCall TC4 Connection of an alarm Connection of an external following text message command must be sent to the ThermoCall TC4: system installed in the vehicle temperature sensor 1234NBANK:XXX:YYY:ZZZ:VVV: (Advanced) (Advanced) The vehicle owner receives a text This is required for measuring the... -
Page 13: Connection To Heater
ThermoCall TC4 Connection to heater Thermo Top Evo or Thermo Top E/C Thermo Top Evo or Thermo Top E/C Thermo Top Evo or Thermo Top E/C -Connect wiring harness to GSM mod- with MultiControl (Advanced) with Telestart T91/T100 HTM ule. -
Page 14: Summer/Winter Connection (Only Advanced, Only For Thermo Top E/C)
ThermoCall TC4 and put it into operation accord- ing to the operating instructions. -To query the firmware version send the text message command "VERSION" to the ThermoCall TC4 NOTE Check that the indicator lamp in the button is functioning correctly. -
Page 15: Technical Data
ThermoCall TC4 Technical data Values Entry Advanced Rated voltage 12 V DC Rated voltage 12 / 24 V DC Bias current consumption 0.005 A Current consumption during data transfer 0.040 A ... -
Page 16: Drawing Of Installation Location For Gsm Module In Vehicle
ThermoCall TC4 Drawing of installation location for GSM module in vehicle Note or sketch the installation location of the GSM module in the following field for possible service cases. - Page 17 In multilingual versions the German language is binding. The telephone number of each country can be found in the Webasto service center leaflet or the website of the respective Webasto representative of your country. Webasto Thermo & Comfort SE Postfach 1410...
