PREPARATION (Continued)

Power Connection

Household
power outlet
Plug into power
outlet.
AC cord
Note:
• Use a commercially available AC plug adapter, if necessary, depending on the design of the wall outlet.
• Always turn the main power switch of the LCD TV set to OFF when connecting the AC adapter.
• Always unplug the AC adapter from the product and power outlet when not using for long periods of time.

Antenna Connection

• Using the supplied antenna cable, connect the room
antenna terminal to the antenna terminal on the TV set.
(Refer to the figure below.)
Room antenna terminal
(75-ohm type)
POWER INPUT terminal
(DC 12V)
AC adapter
ANT. (Antenna terminal)
Antenna cable (supplied)
To antenna terminal
7
