In the interests of user-safety (Required by safety regulations in some countries) the set should be restored
to its original condition and only parts identical to those specified should be used.
» IMPORTANT SERVICE SAFETY PRECAUTION .........................................................................................2
» SPECIFICATIONS ........................................................................................................................................5
» OPERATION MANUAL .................................................................................................................................6
» DIMENSIONS ...............................................................................................................................................8
» REMOVING OF MAJOR PARTS ................................................................................................................ 10
» ADJUSTING PROCEDURE OF EACH SECTION ..................................................................................... 15
» PUBLIC MODE SETTING PROCEDURE ..................................................................................................20
» TROUBLE SHOOTING TABLE ..................................................................................................................35
» MAJOR IC INFORMATIONS ...................................................................................................................... 39
» CHASSIS LAYOUT .....................................................................................................................................42
» BLOCK DIAGRAM ......................................................................................................................................44
» OVERALL WIRING DIAGRAM ...................................................................................................................46
» DESCRIPTION OF SCHEMATIC DIAGRAM ............................................................................................. 48
» SCHEMATIC DIAGRAM ............................................................................................................................. 49
» PRINTED WIRING BOARD ASSEMBLIES ................................................................................................77
» REPLACEMENT PARTS LIST.................................................................................................................... 88
» PACKING OF THE SET ............................................................................................................................103
SHARP CORPORATION
SERVICE MANUAL
LCD COLOR TELEVISION
LC-13B6U-S
LC-15B6U-S
MODELS
CONTENTS
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
LC-13B6U-S
LC-15B6U-S
S74Y3LC13B6US
