LOCATION OF USERS CONTROL (Continued)
Main unit (rear view)
VIDEO
AUDIO (L)
AUDIO (R)
S-VIDEO
ANT. (Antenna terminal)
Y
P
B
P
R
AUDIO (L)
AUDIO (R)
POWER INPUT
(DC12V)
Round lock for Kensington
Security Standard Slot.
Stand
G The screen can be
adjusted backwards to
an angle between 12
and 35 degrees.
When changing the
angle, make sure to hold
the stand and adjust to
the best viewable angle.
* Be careful to prevent the
product from falling over
when adjusting the angle.
Also place the product on
a stable base.
AV-IN1
COMPONENT
Carrying handle
AUDIO (R)
AV-OUT
AUDIO (L)
VIDEO
S-VIDEO
AV-IN2/OUT
