LED Indicators

The LED Indicators are located on the front of the unit and are green in colour, except the
Power LED which is red. The meanings are as follows:
Label
Power
PPP
ADSL
WLAN
(NB5Plus4W)
USB
LAN 4, 3, 2 & 1
NB5Plus4/W Quick Start Guide
8
Status
On
Off
Flashing
On
Off
On
Flashing
On
Flashing
On
Flashing
Flashing
On
Off
Indicates
Power is on.
Power is off.
Trying to authenticate with ISP's PPP server.
PPP link is up.
No PPP link available.
A valid ADSL connection.
An active WAN session.
Wireless link is enabled on NB5Plus4W.
Data is being transmitted wirelessly.
PC connected to USB port.
Data is being transmitted between NB5Plus4/
W and PC.
Flashes when data is being sent or received
on the LAN connection.
Indicates a link to your LAN or Network
card is active.
Indicates no link to LAN.
