NB5Plus4W Antenna Instructions

Before continuing with the Hardware installation, you may need to connect the Antenna
1. The antenna has a retaining nut which must be screwed into the SMA connector on the
back of the modem. Place the screw retaining nut over the antenna connection on the rear
of the NB5Plus4W and turn it clockwise.
Note: Do not over-tighten the attaching nut - but do make sure that you have
screwed it all the way to its end.
Screw retaining
nut clockwise
over the antenna
Bend the antenna to a 90 o angle.
2.
Note: Please note that you may have to rotate the complete antenna assembly to
do this and have the antenna pointing vertically.
NB5Plus4/W Quick Start Guide
14
connection
Bend antenna
o
to a 90 angle
YML755Rev1
