Display Only POWER-ON sequences
Set time for the current step
+ 60 msec
+ 240 msec
+ 60 msec
+ 330 msec
Display-only POWER-OFF sequences
Set time for the current step
+ 4120 msec
+ 120 msec
+ 760 msec
+ 240 msec
5
6
Elapsed time
Display only POWER ON start, Various initial settings 1
All keys are masked.
0 msec
The normal operation keys are masked.
POWER MUTE ON
SYSTEM POWER1 ON (Pin 91: H)
Various initial settings 2
60 msec
Various initial settings 3
Switched 5 V ON completed (power supply is stabilized)
300 msec
Masking of the normal operation keys is canceled.
SYSTEM POWER2 ON (Pin 92: H)
Various initial settings 4
360 msec
Power-on of the LCD driver starts.
Display Only POWER ON completed
690 msec
Elapsed time
Display-only POWER OFF start, Various settings 1
• The mask flags for all the keys are set.
0 msec
• The mask flags for the normal operation keys are set.
• Muting the power system (SYSTEM MUTE REQUEST)
• Power-off of the LCD driver starts.
Various settings 2
4120 msec
Various settings 3
4240 msec
Various settings 4
• The mask flags for all keys are set.
5000 msec
• Muting of the power system is canceled.
• Other than in an emergency power-off, the unit awaits for a while.
• SYSTEM POWER2 OFF (Pin 92: H)
Display-only POWER OFF completed
5240 msec
• SYSTEM POWER1 OFF (Pin 91: H)
