VTech IP Phone Configuration
Guide
Version 1.1
Date: January 28th, 2016
Yeastar Information Technology Co. Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VSP715A and is the answer not in the manual?

Questions and answers

Related Manuals for VTech VSP715A

Summary of Contents for VTech VSP715A

  • Page 1 VTech IP Phone Configuration Guide Version 1.1 Date: January 28th, 2016 Yeastar Information Technology Co. Ltd.

  • Page 2: Table Of Contents

    VTech IP Phone Configuration Guide Contents INTRODUCTION.............................3 FOR VSP715A/725A/735A IP PHONES.................... 4 Environment.......................... 4 Configuration.........................4 1. Configuring account.....................4 2. Configuring voicemail....................7 3. Configuring programmable key..................8 FOR VSP600A DECT PHONE......................9 Environment.......................... 9 Configuration.........................9 1. Connecting the VSP600A DECT base station............9 2.

  • Page 3: Introduction

    VTech IP Phone Configuration Guide Introduction This guide shows you how to manually configure the VTech IP Phones with MyPBX. It has been tested with the latest firmware version supported by MyPBX firmware version X.19.0.47. Including Models:  VSP715A IP Phone ...

  • Page 4: For Vsp715A/725A/735A Ip Phones

    Configuration 1. Configuring account Generally it is recommended that you deploy the VTech IP phone in the same IP segment with MyPBX so that there can communicate with each other. Then log in the web interface of VTech VSP735A. Go to the menu (System>SIP Account Management), and select one account to configure.
  • Page 5 VTech IP Phone Configuration Guide Authentication Name: fill in the register name of MyPBX extension. Authentication Password: fill in the password of MyPBX extension. SIP Server Server Address: the IP address of MyPBX. Port: the SIP port of MyPBX, by default, it is 5060 on MyPBX.
  • Page 6 VTech IP Phone Configuration Guide Figure - Account Page To get the extension registration information, you can log in the web interface of MyPBX. Go to the menu (PBX>Extensions>FXS/VoIP Extensions), and open the right extension edit page. 6/17...

  • Page 7: Configuring Voicemail

    VTech IP Phone Configuration Guide Figure - MyPBX Extension Edit Page Then go to the Status page of VTech VSP735A to check if the account registers successfully. 2. Configuring voicemail On the account page, find the field “Voicemail” under Feature Access Codes section, and fill the MyPBX default voicemail code *2 in it.

  • Page 8: Configuring Programmable Key

    VTech IP Phone Configuration Guide Figure - Voicemail Configuration 3. Configuring programmable key For programmable key, usually we will use BLF and In Call DTMF with MyPBX. BLF works for monitoring extensions status. In Call DTMF is used to dial DTMF during an active call.

  • Page 9: For Vsp600A Dect Phone

    VTech IP Phone Configuration Guide For VSP600A DECT Phone Configuring VSP600A DECT Phone with MyPBX. The VTech DECT Phone contains a DECT base station and one or more handsets. Environment This configuration guide is based on the following software versions: VSP600A base station: 1.1.2.A...

  • Page 10: Configuring Account

    Figure - VSP600A DECT Base Station Web Interface 2. Configuring account Log in the web interface of VTech VSP600A DECT base station. Go to the menu (System>SIP Account Management), and select one account to configure. Next, follow the recommended configuration of the account page in the following: General Account Settings Enable Account: checked.
  • Page 11 VTech IP Phone Configuration Guide Server Address: the IP address of MyPBX. Port: the SIP port of MyPBX, by default, it is 5060 on MyPBX. Registration Server Address: the IP address of MyPBX. Port: the SIP port of MyPBX, by default, it is 5060 on MyPBX.

  • Page 12: Configuring Voicemail

    VTech IP Phone Configuration Guide Figure - MyPBX Extension Edit Page Then go to the Status page of VTech VSP600A base station to check if the account registers successfully. 3. Configuring voicemail On the account page, find the field “Voicemail” under Feature Access Codes section, and fill the MyPBX default voicemail code *2 in it.

  • Page 13: Registering The Handset To The Base Station

    VTech IP Phone Configuration Guide 4. Registering the handset to the base station On the handset, go to the menu (User settings>Registration). Select Handset, and press NEXT to start registration. On the base station, press the HANDSET LOCATOR button for at least four seconds, then release the button.
  • Page 14 VTech IP Phone Configuration Guide Next, go the menu Account Assignment to assign account for handset. Figure - Account Assignments Page After the above steps, you can start to test calls. 14/17...

  • Page 15: For Vcs754A Conference Phone

    IP segment with MyPBX so that there can communicate with each other. Then log in the web interface of VTech VCS754A conference phone. Go to the menu (System>SIP Account Management), and select one account to configure. Next,...
  • Page 16 VTech IP Phone Configuration Guide Server Address: the IP address of MyPBX. Port: the SIP port of MyPBX, by default, it is 5060 on MyPBX. Figure - Account Page To get the extension registration information, you can log in the web interface of MyPBX.

  • Page 17: Testing Calls

    VTech IP Phone Configuration Guide Figure - MyPBX Extension Edit Page Then go to the Status page of VTech VCS754A conference phone to check if the account registers successfully. 2. Testing calls Once the account is available on VTech VCS754A conference phone, you can start to test calls.
