Exposure Index; White Balance; Weight; Power - AJA CION Operation Manual

Exposure Index

White Balance

Weight

Power

Temperature Range

CION v1.2r4
• 320
• 500
• 800
• 1000
• 3200K
• 4500K
• 5600K
• Preset/Auto White Balance
• 6.4 lbs / 2.9 kg (without top handle attached)
• 7.4 lbs / 3.4 kg (with top handle attached)
• AC Range: 100-240 VAC 50/60Hz (AC adapter)
• DC Range: 12-18Vdc, 5A maximum
• (4-pin XLR connector or 2-pin input connector)
• Consumption: 38-42W typical, 45-47W maximum (Note: does not include power draw
from 2-pin output connector)
• Output: 2-pin power output connector, 10W recommended maximum
• Safe Operating Temperature Range: 5C to 40C
• Safe Storage Temperature Range (power OFF): -30C to 70C
91 www.aja.com
