CONFIG Menu Parameters

1.3 Progressive Playback

1.5 Crop SDI 1-4 Output

1.6 SDI 1-4 Output

CION v1.2r4
CONFIG contains general configuration options for:
• Audio and video settings
• Superimposed output information
• Audio and video signal generators and more
Press the CONFIG Menu Button to enter the CONFIG menu parameters. Rotate the User
Interface Control Knob to review the various menu parameters and selections.
NOTE: The default parameter in the following menus is highlighted in bold typeface.
This parameter defines how progressive recordings are output. Unless you are connected
to a CRT monitor that may require PsF, it is best to leave the menu parameter configured
for the default of progressive output.
These are the options:
• Progressive (default) – Playback as progressive frame
• PsF – Playback as progressive segmented frame
NOTE: To ensure HDMI output during playback, "Progressive" needs to be selected.
NOTE: PsF is disabled as a selection when working with 4K or Ultra HD formats.
This parameter enables or disables a cropped output for the main SDI 1-4 outputs.
These are the options:
• OFF (default) – No crop is applied to the SDI 1-4 outputs
• ON – Crops 4K (4096x2160) to (3840x2160) Ultra HD output or crops 2K (2048x1080) to
(1920x1080) HD output
NOTE: Some monitors and devices connected to CION may not offer support for 4K (4096x2160) or
2K (2048x1080) and you may need to enable the crop feature to properly interact with these
devices. Be sure to consult your device's technical specifications to see what formats and
frame rates it supports.
NOTE: Enabling the crop feature has no impact if Ultra HD, 1080p or 1080i video has been
configured in the FPS menu.
This menu parameter determines the type of output used by the SDI 1-4 Main Outputs.
These are the options:
Table 1. SDI Output Parameter Options
SDI 1-4 RGB (default)
SDI 1-4 YCbCr
SDI 1-4 RAW
Sets SDI 1-4 outputs to RGB (supports up to 4K 30 fps)
Sets SDI 1-4 outputs to YCbCr (supports up to 4K 60 fps)
Sets SDI 1-4 to RAW (supports up to 4K 120 fps)
