Chapter 5: User Interface Navigation

Overview

Default Display for the User Interface Screen

CION v1.2r4
There are two ways to control CION:
• From the operator side using the menu buttons and the User Interface Control Knob
• Remotely from a web browser connected using CION's LAN connection
This chapter discusses configuring CION using the menu buttons and the User Interface
Control Knob. For Web Browser control information, refer to
Remote Control on page
The User Interface Screen has a default display mode. With Pak media inserted, the
default display mode has a top line of information that provides the clip name on the left
side and the percentage of the remaining media capacity on the right side.
The second line provides the current reel number on the left side and the timecode for
the clip on the right side.
66".
33
"Chapter 6: Web Browser
