EHC Fusion Installation & Technical Manual page 2

This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning
Children should be supervised to ensure that they do not play with the appliance.
Please read and follow the installation and operating instructions
carefully, to ensure the long life and reliable operation of this
appliance.
The Electric Heating Company may make minor changes
if necessary in the appliance that will not be shown in the
operating instructions, so long as the main features of the boiler
remain the same.
All boilers come with a 24 month warranty that covers all
defects originating from faulty materials and workmanship in the
manufacture of the boilers.
The warranty covers the replacement of any faulty parts and
labour costs.
GB-016C_f.493
INTRODUCTION
PREPARATION
INSTALLATION
ELECTRICAL CONNECTIONS AND CONTROLS
EXTERNAL CONTROL WIRING
INTERNAL BOILER WIRING
EXTERNAL BOILER WIRING
BOILER DIMENSIONS
USER INSTRUCTIONS
FAULT FINDING
TECHNICAL SPECIFICATIONS
use of the appliance by a person responsible for their safety.
INTRODUCTION
Page Contents
The warranty will not cover any damage to the boiler from poor
or incorrect installation work.
The warranty will not cover any call out charges that are a user
or external control fault.
The warranty will not cover water leaks into the boiler. All
plumbing joints must be checked.
The warranty card should be completed and sent back to The
Electric Heating Company as soon as possible for registration.
A magnetic filter must be fitted to the system in the horizontal
position.
2
2
3
4
7
8
9
10
10
11
13
14
