EHC Fusion E10 Combi Series
Installation and
technical manual
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND
RETAINED FOR FUTURE REFERENCE.
The Fusion E10 must be installed by a competent person with accordance
with this installation manual and all relevant regualtions in force at time of
installation
The Fusion E10 combination unit's Unvented Cylinder is a controlled service
as defined in the latest edition of the building regulations.
The relevant regulations are:
England and Wales – Building Regulation G3
Scotland – Technical Standard P3
N Ireland – Building Regulation P5
After installation the Benchmark log table on page X must be completed
and left with the householder for future reference.
Unit 40, Block 5, Third Road, Blantyre Industrial Estate, Blantyre, Glasgow, G72 0UP
Tel. 01698 820533
Fax. 01698 825697
Combination Boiler Range
The Electric Heating Company Ltd
info@electric-heatingcompany.co.uk
www.electric-heatingcompany.co.uk
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for EHC Fusion E10 Combi Series
Summary of Contents for EHC Fusion E10 Combi Series
- Page 1 EHC Fusion E10 Combi Series Combination Boiler Range Installation and technical manual THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE. The Fusion E10 must be installed by a competent person with accordance with this installation manual and all relevant regualtions in force at time of installation The Fusion E10 combination unit’s Unvented Cylinder is a controlled service...
-
Page 2: Table Of Contents
Benchmark Service Record Guarantee Warranty registration Please ensure that the warranty card is completed and returned to the EHC by post, or you can register the Combination Unit online at www.electric-heatingcompany.co.uk. Fusion E10 Combi – Installation and technical manual Page 2... -
Page 3: Introduction
Introduction Thank you for specifying the Fusion E10 Combi Boiler from The Electric Heating Company. The Fusion Combi is an integrated electric flow boiler and indirect heated Duplex SSTL unvented domestic heating cylinder with back up immersion heater. This appiance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by the person responsible for their safety. -
Page 4: Storage, Handling & Unpacking
Storage, handling & unpacking The Fusion E10 Combi is protected in corrugated packaging with reinforced corner posts. The assembly is wrapped in heavy duty polythene. The Fusion E10 Combi unvented fitting kit is supplied within the boiler. The assembly must be stored upright, under cover in dry conditions. -
Page 5: Contents Check List
Contents check list The following components are supplied in the bag at the front of the Fusion E10 Combi cabinet. Please check that all parts are present and available before commencing installation. Fusion E10 Combi – Installation and technical manual Page 5... -
Page 6: Key Components
Key components Enclosure Removable door retaining clips Twin channel programmer Fusion Slimline Boiler Rear compartment – expansion vessels Rear compartment – cylinder Automatic bypass Cylinder stat Wiring centre 10 Domestic hot water temp/pressure relief outlet 11 Programmer cable 12 Domestic hot water outlet 13 Central heating pressure relief outlet 14 Magnetic filter 15 Zone valves... -
Page 7: Technical Specifications
Technical specifications________________________ General Boiler range Cylinder 9 kW 12 kW 14.4 kW Heating output 30,717 Btu 40,956 Btu 49,147 Btu Electricity Supply 230/240V single phase 50Hz Load/Current 39.1 Amps 52.2 Amps 62.6 Amps Protection required 45.0 Amps 63.0 Amps 80.0 Amps CH Max temp setting 85°C 55/60°C... - Page 8 Technical specifications/ Cont..._________________ Dimensions 150 litre 180 litre Dry weight 96 kg 104 kg Full weight 250 kg 290 kg Dimensions 1470 x 574 x 750 mm 1620 x 574 x 750 mm Recommended Clearance 200mm 50mm 20mm Fusion E10 Combi –...
-
Page 9: Installation: Siting
Installation: siting Choosing a location The Fusion E10 Combi must be installed indoors in a dry and frost free environment. It must be vertically mounted on a flat, level surface capable of supporting the full weight of the unit. When full the unit weighs a total of 250kg - 290kg. Consideration must be given to maintenance –... -
Page 10: Installation - Plumbing
Installation: Plumbing Water supply requirements The Fusion E10 Combi operates at 3 bar (controlled by the inlet control set) and is capable of delivering over 50 litres per minute. The high quality inlet control set has been designed to make the most of the flow rates available, however the performance of any unvented system is only as good as the mains water supply to the unit. - Page 11 Installation: Plumbing/ Cont.. Balanced cold connection If the system includes showers, bidets or monobloc taps, then a balanced cold supply is necessary. Do not use monobloc mixer tap or showers if the balanced cold connection is not used. Outlets of this type can back-pressurise the unit and result in discharge. A 22mm balanced cold mains outlet can be found on the control set supplied, (see diagram below) Use the balanced cold mains outlet from the inlet control set (as shown in the illustration) to...
-
Page 12: Installation - Discharge Arrangement
Installation: discharge arrangement The above diagram is of a typical discharge pipe arrangement. (extract from Building Regulation G3) Note: The discharge will consist of scalding water and steam. Asphalt, roofing felt and non- metallic rainwater goods may be damaged by such discharges. Note: It is not acceptable to discharge straight into a soil pipe. - Page 13 Installation: discharge arrangement /cont C) Be installed with a continuous fall. D) It is preferable for the discharge to be visible at both the tundish and the final point of discharge but where this is not possible or practically difficult there should be clear visibility at one or other of these locations.
-
Page 14: Installation - External Pipework Schematic
Installation: External pipework schematic Fusion Electric Boiler Cylinder Fusion E10 Combi – Installation and technical manual Page 14... -
Page 15: Installation – Central Heating Pipework
Installation: Central Heating pipework____________ Flow and return connections are located at the bottom of the left hand side of the unit. We recommend compression joints at this point to prevent damage to the units internal seals. The return connection will need to temporarily incorporate a filling loop as shown in the diagram below. -
Page 16: System Pressures
Installation: Central Heating pipework/Cont_________ System Pressures The normal working pressure of the Fusion E10 boiler should be set to 1.5 bar. All sealed systems should comply with current building regulations and standrads All Fusion E10 Combi units are water and pressure tested before leaving the factory. However all compression joints must be checked again at installation due to the possibilty of transit movement. -
Page 17: Installation – Electrical
Installation – Electrical All electrical connections must be made by a qualified person. All wiring must be carried out in accordance with current IEE regulations. BS7671 (17th edition) THIS APPLIANCE (including all pipework) MUST BE EARTHED A load check should be carried out to ensure that there is sufficient current and voltage for the intended boiler installation. - Page 18 Installation – Electrical/ Cont. Fusion boiler mains power supply TLX4101 Room Thermostat (supplied) Volt free connections from thermostat Fusion E10 Combi – Installation and technical manual Page 18...
- Page 19 Installation – Electrical/Cont. Combination Unit -Control Wiring Fusion E10 Combi – Installation and technical manual Page 19...
-
Page 20: Filling The Cylinder
Commissioning: Genaral IMPORTANT: DO NOT SWITCH ON THE ELECTRICAL SUPPLIES TO THE FUSION E10 COMBI UNIT UNTIL THE CYLINDER AND PRIMARY CIRCUIT HAVE BEEN CORRECTLY FILLED WITH WATER. Filling the cylinder 1 Check that all pipe connections to the Fusion E10 Combi are tight. 2 Open a hot tap furthest from the Fusion E10 Combi. -
Page 21: Commissioning – General
Commissioning General/Cont. Check Safety Valves Operation 1 Check Temperature and Pressure Relief Valve 2 Check pressure relief valve on reducing set 3 Check that all pressure relief valves flow through tundish outlet Preliminary Electrical Checks 1 Check all electrical connections are tight. Loose connections can cause over-heating of terminals and the possibility of a fire. - Page 22 Commisioning: Programmer The programmer allows you to set ON OFF time periods. Some models switch the domestic hot water on and off at the same time, while others allow the domestic hot water and heating to come on and go off at different times.Set the ‘On’ and ‘Off’ time periods to suit your own lifestyle. On some programmers you must also set whether you want the heating and hot water to run continuously, run under the chosen ‘On’...
- Page 23 Commisioning: Programmer/Cont. Setting the date and time Press the SET button and the clock icon on the screen will flash. Press the +/- buttons to adjust the time. Hold down the button to change the time quicker. Press SET button till the Y:00 icon (year) appears and the letter D flashes. Press the +/- button to set the year.
- Page 24 Commisioning: Programmer/Cont. If the unit installed is a 7 day programmer, the initial programme displayed will be for Monday. You can go to any day of the week by pressing the DAY button repeatedly. The ON/OFF times can be changed for each day as above in the “changing programme times”. If you press the COPY button, the current programme will be copied onto the next day.
- Page 25 Commisioning: Programmer/Cont. The display indicates how many hours have been requested in the bottom left hand corner. Hot Water can be temporarily switched on in the same way, using the +HR button on the right of the display. Power interruption In the event of a mains supply failure, the back-up battery ensures the programmer continues to keep time and retain your stored programme.
-
Page 26: Boiler Operation
Commissioning: Fusion boiler instructions________ Introduction Unlike other system boilers such as Gas, Oil and Propane, the FUSION range of electric boilers require no ignition or lighting sequence to be executed by the end user. All the end user is required to do is ensure that the system is filled with water and the room stat or programmer is calling for heat. -
Page 27: Commissioning – Fusion Boiler
Commissioning: Fusion boiler instructions/Cont.____ Front Control Panel Indicator B When GREEN light is on the pump is operating. When this light flashes the flow rate is insufficient (less than 5 ltr per min) Refer to technical specifications Indicator C When light is off room thermostat temperature has been achieved. (RP is open) When the green light flashes the NA connection is open. -
Page 28: Servicing
Servicing Servicing should only be carried out by competent installers and any spare parts used must be purchased from The Electric Heating Company. NEVER bypass any safety devices or operate the unit without them being fully operational. Draining Isolate from the electrical supply to prevent the immersion heaters burning out. Isolate the unit from the cold mains. -
Page 29: Trouble Shooting
Trouble Shooting SYMPTOM REASON SOLUTION Water escaping from Possible transit movement Check and tighten all internal unit compression connections Possible programmer settings Check programmer is set for desired time settings Dual thermostat set to low Set dual thermostat to 60 deg Cold water from taps Check dual stat over heat Dual thermostat over heat... -
Page 30: Trouble Shooting
Trouble Shooting/Cont. SYMPTOM REASON SOLUTION Possible programmer Check programmer is set for desired No heating to radiators settings time settings Pressurise to 1.5 bar Low boiler pressure System must have a minimum of 5 Lpm to operate (press right arrow key on boiler until L/min is eliminated No heating and hot Poor flow rate... -
Page 31: Benchmark Service Record
Benchmark Service Record______________________ Fusion E10 Combi – Installation and technical manual Page 31... -
Page 32: Guarantee
Guarantee The Fusion E10 Combination Unit is guaranteed against faulty materials or manufacture provided that: It has been correctly installed as per this It has not been subjected to frost damage document and all the relevant standards, regulations and codes of practice in force at the ... -
Page 33: Ehc Fusion E10 Combi – Installation And Technical Manual
Fusion E10 Combi – Installation and technical manual Page 33...
