Technical Specifications - EHC Fusion Installation & Technical Manual

Boiler range
Pipe entry from boilers
Central heating flow & return pipes
Min water pressure
Max water pressure
Expansion vessel
Vessel charge pressure
Dry weight
Electrical supply
Load/current
Heating output
Temp setting (factory set)
Min temp setting
Overheat Protection
Pump included
Recommended Pump settings
Protection
The maximum allowed network impedance
NB: Voltage free control connections
GB-016C_f.493

TECHNICAL SPECIFICATIONS

Fusion 6kW Fusion 9kW Fusion 12kW
EHCFUS EHCFUS
6kW 9kW
Bottom Bottom
Entry Entry
maximum system water volume about 60 litres at initial system pressure 1,5 bar
240V 1ph 50Hz
240V; 25,0 A 240V; 37,5 A 240V; 50,0 A
20,478 Btu 30,717 Btu
32 A 45 A
0,39 Ω 0,32 Ω
Boiler Dimensions
Width 420mm
Height 700mm
Depth 285mm
14
Fusion 14.4kW Fusion 24kW
EHCFUS EHCFUS
12kW 14,4kW
Bottom Bottom
Entry Entry
22 mm
1 bar
3 bar
6 lt.
1,5 bar
25kg
240V; 60,0 A 415V; 33,4 A
40,956 Btu 49,147 Btu
85°C
40°C
100°C
Yes
Set to max
63 A 80 A
0,24 Ω 0,22 Ω
Controls
Central Heating Only:
EHC Single Channel Heat Pack
Central Heating & Domestic Hot Water:
EHC Twin Channel Heat Pack
The Electric Heating Company Ltd
Unit 40, Block 5
Third Road
Blantyre Industrial Estate
Blantyre
Glasgow
G72 0UP
Tel: 01698 820533 Fax: 01698 825697
Fusion 30W Fusion 36kW
EHCFUS EHCFUS
24kW 30kW
Bottom Bottom
Entry Entry
415V 3ph N 50Hz
415V; 41,8 A 415V; 50,1 A
81,912 Btu
40 A 45 A
EHCFUS
36kW
Bottom
Entry
63 A
