Quick Start

To attach the MultiSync FE1250+ monitor to your system, follow these
instructions:
1. Turn off the power to your computer.
2. If necessary, install the display card into your system. For more
information, refer to the display card manual.
3. For the PC: Connect the 15-pin mini D-SUB of the captive signal
cable to the connector of the display card in your system
(Figure A.1). Tighten all screws.
For the Mac: Connect the Macintosh cable adapter (not included) to
the monitor connector on the Macintosh (Figure B.1). Attach the
15-pin mini D-SUB end of the captive signal cable to the Macintosh
cable adapter on the computer (Figure B.1). Tighten all screws.
4. The Windows
found on the CD-ROM, delivered with the monitor.
5. Connect one end of the power cord to the MultiSync FE1250+
monitor and the other end to the power outlet (Figure C.1).
6. Turn on the monitor (Figure D.1) and the computer.
NOTE: If you have any problems, please refer to the
Troubleshooting section of this User's Manual.
® 95/98/2000 INF file for your MultiSync monitor can be
Captive Signal Cable
Figure A.1
English-8
15-pin mini D-SUB
