Specifications - LCD4615

Product Specifications
LCD Module
Frequency
Pixel Clock
Viewable Size
Input Signal
RGB1 DVI-D 24pin
RGB2 15pin Mini D-sub
RGB3 BNC (R,G,B,H,V)
DVD/HD BNC (Y, Cb/Pb, Cr/Pr)
VIDEO(S) Mini DIN 4 pin
VIDEO BNC
RCA
Output Signal
RGB 15pin Mini D-sub
VIDEO BNC
AUDIO
AUDIO RCA (L/R) X2
Input STEREO Mini Jack
AUDIO RCA (L/R)
Output
Speaker Output
Control
Power Supply
Operational Environment
Storage Environment
Dimension
Weight (Without stand)
VESA compatible arm mounting interface
Complied Regulatory and Guidelines
Power Management
Plug & Play
Accessories
NOTE: Technical specifications are subject to change without notice.
46"/116.8 cm diagonal
Pixel Pitch: 0.530 mm
Resolution: 1920 x 1080 dots
Color: Over 16 million colors (depending on video card used)
2
Brightness: 450 cd/m
Contrast Ratio: 3000:1
Viewing Angle: 89° (typ) @ CR>10
Design View Distance: 1300 mm
Horizontal: 15.625/15.734 kHz, 31.5 kHz - 91.1 kHz
Vertical: 50.0 - 85.0 Hz
25.0 MHz - 165.0 MHz
1018.08 x 572.67 mm
Digital RGB DVI (HDCP)
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
Analog RGB 0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
Sync Separate: TTL level (Pos./Neg.)
Analog RGB 0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
Sync Separate: TTL level (Pos./Neg.)
Component Y: 1.0 Vp-p/75ohm, Cb/Cr (Pb/Pr): 0.7 Vp-p/75 ohm
HDTV/DVD: 1080i@60Hz, 1080p@60Hz, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz
S-VIDEO Y: 1.0 Vp-p/75 ohm C: 0.286 Vp-p/75 ohm (NTSC), 0.3 Vp-p/75 ohm (PAL/SECAM)
NTSC/PAL/SECAM/4.43NTSC/PAL60
Composite 1.0 Vp-p/75 ohm
NTSC/PAL/SECAM/4.43NTSC/PAL60
Analog RGB 0.7 Vp-p with 75 ohm terminated
Separate HV sync: TTL level (Pos. / Neg.)
Composite 1.0 Vp-p with 75 ohm terminated
Analog Audio Stereo L/R 0.5 Vrms
Analog Audio Stereo L/R 0.5 Vrms
External Speaker Jack 7 W + 7 W (8 ohm)
RS-232C In: 9 Pin D-sub
2.4 - 1.0 A @ 100-240VAC, 50/60Hz
Temperature: 5 - 40°C (landscape), 5 - 35°C (portrait)
Humidity: 20 - 80% (without condensation)
Altitude: 0 - 3000 m
Temperature: -20 - 60°C
Humidity: 10 - 90% (without condensation)/ 90% - 3.5% x (Temp - 40°C) regarding over 40°C
Net: 1121.5 (W) x 664.7 (H) x 129.8 (D) mm (without stand)
Gross: 1270 (W) x 769 (H) x 275 (D) mm
Net: 23.9 Kg
Gross: 29.5 Kg
200 mm x 200 mm (4 Holes)
UL60950-1/CSA C22.2 No.60950-1/ TUV-GS/EN60950-1
FCC-B/DOC-B/EN55022-B/EN55024/EN61000-3-2/EN61000-3-3/CE/GOST-R
VESA DPM
VESA DDC2B, DDC/CI
Setup manual, Power Cord, Video Signal Cable, Remote Control, AAA Battery x 2, Clamp x 2,
Screw for Main switch cover x 2, Screw for Clamp x 2, CD-ROM, Thumbscrew for stand x 2,
Main switch cover
(Typ.)
English-31
1 1
, 1920 x 1080* (60Hz)
1 , 1920 x 1080* 1 (60Hz)
1 , 1920 x 1080* 1 (60Hz)
*1: Compressed image
