Installation

To attach the MultiSync LCD1525X monitor to your system, follow these
instructions:
1. Turn off the power of your computer.
2. For the PC with DVI digital output: Connect the DVI-D to DVI-D
signal cable to the connector of the display card in your system
(Figure A.1). Tighten all screws.
For the PC with analog output: Connect the DVI-A to VGA cable to
the connector of the display card in your system (Figure A.2).
To connect a secondary PC with analog output, connect the
MultiSync LCD1525X D-SUB to D-SUB (not included) cable to the
connector of the display card in your system.
For the Mac: Connect the MultiSync Macintosh cable adapter to the
computer (Figure B.1). Attach the 15-pin mini D-SUB signal cable to
the MultiSync Macintosh cable adapter (Figure B.1).
NOTE: Macintosh G3 and G4 do not need a Macintosh cable
adapter.
3. Remove connector cover and cable cover. Connect the DVI signal
cable to the connector on the back of the monitor. Place the DVI
video signal cable under Clip A.
Replace connector cover and cable cover.
4. Using the USB cable, connect the B type connector to the USB
upstream port on the back of the monitor and A type connector to the
downstream part on the computer (Figure D.1). If you are using the
cord from the USB device, use one of the downstream ports on the
side of the monitor (Figure E.1).
NOTE: Incorrect cable connections may result in irregular
operation, damage display quality/components of LCD
module and/or shorten the module's life.
5. Connect one end of the power cord to the MultiSync LCD Series
monitor and the other end to the power outlet (Figure F.1).
6. Turn on the monitor (Figure G.1) and the computer.
English-16
