Specifications

Monitor Specifications
Display
Input Signal (Analog)
Input Signal (Digital)
Display Colours
Synchronization Range
Resolutions Supported Analog input:
Active Display
Area**
Power Supply
Current Rating
Dimensions
Weight
Environmental Considerations
Operating Temperature:
Storage Temperature:
* Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD
module, text may appear different. This is normal and necessary for all current flat panel technologies
when displaying non-native resolutions full screen. In flat panel technolo-gies, each dot on the screen is
actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
** Active display area is dependent upon the signal timing.
NOTE: Technical specifications are subject to change without notice.
MultiSync LCD1525X
38 cm (15.0 inch) viewable image size; 1024 x 768 native
resolution (Pixel Count); active matrix; thin film transistor
(TFT); liquid crystal display (LCD); 0.30 mm dot pitch;
200 cd/m
typical
Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
TMDS
16777216 colors (Depends on the graphics board)
Horizontal:
24.8 kHz to 60.0 kHz (Automatically)
Vertical:
56.2 Hz to 75.1 Hz (Automatically)
720 x 400*: VGA text
640 x 480* at 60 Hz to 75 Hz
800 x 600* at 56 Hz to 75 Hz
832 x 624* at 75 Hz
1024 x 768 at 60 Hz to 75 Hz
Digital input:
640 x 400* at 60 Hz
720 x 400* at 60 Hz to 70 Hz
640 x 480* at 60 Hz to 75 Hz
800 x 600* at 56 Hz to 75 Hz
832 x 624* at 75 Hz
1024 x 768 at 60 Hz to 75 Hz
Horizontal: 304 mm
Vertical: 228 mm
AC 100-240 V @50/60 Hz
0.75 A @ 100-120 V / 0.45 A @ 220-240 V
370 (W) x 360 (H) x 158 (D) mm
4.5 kg
5 °C to 35 °C
30% to 80%
Humidity:
-10 °C to +60 °C
10% to 85%
Humidity:
English-27
2 white luminance, typical; 350:1 contrast ratio,
