Controls

OSM (On-Screen-Manager) Controls

The OSM controls on the front of the monitor function as follows:
To access OSM press any of the control buttons ( , , , ) or the
PROCEED button
Control
EXIT
CONTROL /
CONTROL /
PROCEED
RESET
The currently
highlighted
control to
factory setting.
NOTE: When RESET is pressed, a warning window will appear
allowing you to cancel the reset function.

Brightness/Contrast Controls

Main Menu
Exits the OSM controls.
Moves the highlighted
area up/down to select
one of the controls.
Moves the highlighted
area left/right to select
control menus.
Has no function.
Resets all the controls
within the highlighted
menu.
BRIGHTNESS
Adjusts the overall image and background screen
brightness.
CONTRAST
Adjusts the image brightness in relation to the
background.
AUTO ADJUST CONTRAST
Adjusts the image displayed for non-standard video
inputs.
English-10
Sub-Menu
Exits to the OSM controls
main menu.
Moves the highlighted area
up/down to select one of the
controls.
Moves the bar left/right to
increase or decrease the
adjustment.
Activates Auto Adjust and all
RESET functions.
Resets the highlighted control.
