OSM (On-Screen-Manager) Controls

Press MENU button to
open Main menu.
Press UP or DOWN button
to select sub-menu.
Remote Control
Press UP or DOWN
button to select.
Control Panel
MAIN MENU


SCREEN
OSM screen
AUDIO
PIP
CONFIGURATION 1
CONFIGURATION 2
ADVANCED OPTION
:SEL
Denotes an AV unit function.
All AV functions are enabled when the AV unit is installed.
If this product was purchased in Europe the AV unit is preinstalled and all AV functions are available.
Main-Menu
Sub-Menu
BRIGHTNESS
CONTRAST
SHARPNESS
BLACK LEVEL
NOISE
REDUCTION
*:INPUT VIDEO only
Press SET button to
decide.
Press INPUT button
to decide.
UP or DOWN button
SET :NEXT EXIT :RETURN MENU :EXIT MENU
BRIGHTNESS
CONTRAST
SHARPNESS
BLACK LEVEL
COLOR CONTROL
COLOR TEMPERATURE
PICTURE RESET
:SEL SET :NEXT EXIT :RETURN MENU :EXIT MENU
BRIGHTNESS
CONTRAST
SHARPNESS
BLACK LEVEL
COLOR CONTROL
COLOR TEMPERATURE
PICTURE RESET
:SEL SET :NEXT EXIT :RETURN MENU :EXIT MENU
BRIGHTNESS
CONTRAST
SHARPNESS
BLACK LEVEL
COLOR CONTROL
COLOR TEMPERATURE
PICTURE RESET
:SEL SET :NEXT EXIT :RETURN MENU :EXIT MENU
BRIGHTNESS
CONTRAST
SHARPNESS
BLACK LEVEL
COLOR CONTROL
COLOR TEMPERATURE
PICTURE RESET
:SEL SET :NEXT EXIT :RETURN MENU :EXIT MENU
BRIGHTNESS
CONTRAST
SHARPNESS
TINT
COLOR
BLACK LEVEL
NOISE REDUCTION
:SEL SET :NEXT EXIT :RETURN :EXIT MENU
MENU
Press UP or DOWN, and PLUS or
MINUS button to select function, or
control which you like.
Press SET button to decide.
Press UP or DOWN, and PLUS or
MINUS button to select function, or
control which you like.
Press INPUT button to decide.
INPUT button
BRIGHTNESS
CONTRAST
SHARPNESS
BLACK LEVEL
COLOR CONTROL
COLOR TEMPERATURE
PICTURE RESET
:SEL SET :NEXT EXIT :RETURN MENU :EXIT MENU
BRIGHTNESS
32
+ -:ADJ EXIT :RETURN MENU :EXIT MENU
CONTRAST
32
+ -:ADJ EXIT :RETURN MENU :EXIT MENU
SHARPNESS
32
+ -:ADJ EXIT :RETURN MENU :EXIT MENU
BLACK LEVEL
32
+ -:ADJ EXIT :RETURN MENU :EXIT MENU
NOISE REDUCTION
32
+ -:ADJ EXIT :RETURN MENU :EXIT MENU
English-20
PLUS and
MINUS button
BRIGHTNESS
32
+ -:ADJ EXIT :RETURN MENU :EXIT MENU
Adjusts the overall image and background screen
brightness.
Press + button to increase brightness.
Press - button to decrease brightness.
Adjusts the image brightness in relation to the input
signal.
Press + button to increase contrast.
Press - button to decrease contrast.
NOTE: sRGB picture mode is standard and cannot be
changed.
This function is digitally capable of keeping a crisp image
at any timing. It is adjustable to get as distinct an image
or as soft an image as you prefer. It is set independently
for each picture mode.
Press + button to increase sharpness.
Press - button to decrease sharpness.
Adjusts the image brightness in relation to the
background.
Press + button to increase black level.
Press - button to decrease black level.
NOTE: sRGB picture mode is standard and cannot be
changed.
Adjusts the noise reduction level.
Press + button to increase reduction level.
Press - button to decrease reduction level.
Press MENU or EXIT
button to exit.
Press EXIT button
to exit.
EXIT button
BRIGHTNESS
CONTRAST
SHARPNESS
BLACK LEVEL
COLOR CONTROL
COLOR TEMPERATURE
PICTURE RESET
:SEL SET :NEXT EXIT :RETURN MENU :EXIT MENU
MAIN MENU
SCREEN
AUDIO
PIP
CONFIGURATION 1
CONFIGURATION 2
ADVANCED OPTION
:SEL SET :NEXT EXIT :RETURN MENU :EXIT MENU
