OBJ_BUCH-1549-002.book Page 13 Friday, April 27, 2012 8:56 AM

Declaration of Conformity

We declare under our sole responsibility that the product described under "Technical data"
is in conformity with the following standards or standardization documents: EN 60745 ac-
cording to the provisions of the directives 2011/65/EU, 2004/108/EC, 2006/42/EC,
2000/14/EC.
2000/14/EC: Guaranteed sound power level
Conformity assessment procedure according to Annex V.
Equipment category: 25
Technical file (2006/42/EC) at:
Bosch Lawn and Garden Ltd., PT-LG/ENS,
Stowmarket, Suffolk IP14 1EY, England
Dr. Egbert Schneider Helmut Heinzelmann
Senior Vice President Head of Product Certification
Engineering PT/ETM9
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
12.04.2012
Mounting and Operation
Action
Delivery Scope
Connecting the Extension Lead

Troubleshooting

Problem
Hedgecutter does not
operate
Hedgecutter operates
intermittently
Motor runs but blades remain
stationary
Bosch Power Tools
Working Advice
Sawing Function
Although the tooth opening allows wood to be cut up to
Ø 26/34 mm, the tip of the blade is designed to cut wood up
Figure
to Ø 32/38 mm.
1
2
Possible Cause
Power turned off
Mains socket faulty
Inbuilt supply cable damaged
Separate extension cable damaged
Fuse faulty/blown
Inbuilt supply cable damaged
Separate extension cable damaged
Internal wiring of garden product damaged
On/Off switch defective
Internal fault
3 600 ...
dB(A)
Action
Starting
Stopping
Working Advice
Sawing Function
Blade Maintenance
Storage and Transport
Selecting Accessories
Corrective Action
Turn power on
Use another socket
Inspect supply cable carefully, contact Service
Agent for replacement
Inspect extension cable, replace if damaged
Replace fuse
Inspect supply cable carefully, contact Service
Agent for replacement
Inspect extension cable, replace if damaged
Contact Service Agent
Contact Service Agent
Contact Service Agent
English | 13
H47 E.. H47 J..
H47 F.. H47 K..
H47 G..
H47 H..
97 98
Figure
3
3
4
5
6
6
7
F 016 L70 832 | (27.4.12)
