10
Electrical Connection
Wall
Rear
Front
A cable locking connector (not supplied) is also required by local codes. Check with local requirements and codes,
purchase and install the appropriate connector in order to meet all mandatory codes.
10. Insert bolts w/ washers provided
through drill out (A)
11. Lift hood and hook rear opening slots
onto 2 rear brackets previously installed on
wall
INSTALLATION
12. Tilt hood up and fasten left and right
bolts onto hood
13. Connect duct to hood opening, tape all
joints with aluminum duct tape and inspect
for leakage
Cable lock
