SeCTIoN 3: CArbureTIoN ANd Fuel SYSTeM
MANUAL TANK SHUT OFF VALVE
ITEMS INSIDE DASHED
LINE ARE OEM SUPPLIED
LP TANKS
ITEMS OUTSIDE DASHED
LINE ARE GENERAC
SUPPLIED
3
MANUAL TANK
SHUT OFF VALVE
ENGINE
TO
CARBURETOR
PRESSURE
RELIEF
VALVE
SOLENOID
SHUT OFF
VAPORIZOR / ON DEMAND
REGULATOR
NOTE: ALL FUEL LINES ARE REQUIRED TO BE
BRAIDED STAINLESS STEEL COVERED.
Figure 3-32. Typical LP (Liquid) System
3-11
