There are no servicable parts inside the device. Maintenance and service operations are only to be carried
out by authorized dealers.
Should you need any spare parts, please use genuine parts.
Should you have further questions, please contact your dealer.

9. TECHNICAL SPECIFICATIONS

Power supply:
Power consumption:
Number of control-channels:
Sound-control:
DMX 512-output:
Free chasers:
Dimensions (LxWxH):
Minimum mounting depth:
Weight:
Please note: Every information is subject to change without prior notice. 17.04.2003 ©
230 V AC, 50 Hz ~
via 9-12 V DC, 300 mA power unit included in the delivery
4 W
192
via built-in microphone
3-pin XLR-connector with polarity selector
6 x 240 scenes
483 x 132 x 80 mm
19" mounting dimensions with 3 u
170 mm
2.5 kg
