9. TECHNICAL SPECIFICATIONS

Power supply:
Power consumption:
Number of control-channels:
Sound-control:
DMX 512-output:
Free chasers:
Dimensions (LxWxH):
Minimum mounting depth:
Weight:
Please note: Every information is subject to change without prior notice. 23.05.2005 ©
230 V AC, 50 Hz ~
via 9-12 V DC, 300 mA power unit included in the delivery
4 W
192
via built-in microphone
3-pin XLR-connector with polarity selector
6 x 240 scenes
483 x 132 x 80 mm
19" mounting dimensions with 3 u
170 mm
2.5 kg
