Press the Mode and Auto/Del-button at the same time. All LEDs will flash three time. The desired projector
was deleted.
5.4.4 Delete all projector assigns
With this function, you can delete the Pan/Tilt-assign of all projectors.
Switch the device off.
Hold the Mode- and Auto/Del-button at the same time.
Turn the device on again. All LEDs will flash shortly, all DMX-channels are deleted.
5.4.5 Display DMX-channel
With this function, you can display the channel assigned to the Pan/Tilt-movement.
Hold the Mode- and Fine-button at the same time until the Reverse or Assign-LED is lit.
Select the desired projector via the Projector Select-buttons. the display shows the Pan/Tilt-value. E.g. "ASS
01 02" means that Pan is assigned to channel 1and Tilt is assigned to channel 2. "RES 01 02" means that
Pan on channel 1 and Tilt on channel 2 is inverted. If only Pan is inverted, the display shows "RES 01 00".
5.4.6 Assigning the Fade Time
With this function, you can determine if the Fade Time should be assigned only for the Pan/Tilt-movement or
for all DMX-channels. This makes especially sense when the mirror or Moving-Head movement should be
carried out slowly, but the gobos and colours should be changed quickly.
Turn the device off.
Press and hold the Mode and Tap/Display-button at the same time.
Turn the device on again. Press the Tap/Display-button in order to switch between the two modes.
ALL CH
OR
FD TIME
All channels
Press the Mode and Tap/Display-button at the same time in order to memorize your settings. Press the
Blackout-button in order to leave the mode without saving.

6. OPERATION

After you connected the device to the mains, the DMX Scan Control is ready for use.

6.1 Manual-mode

6.1.1 Call up projectors manually
In the Manual-mode (Program-LED off), you can call up the connected projectors manually and control them
via the channel faders. Please note that the adjusted settings cannot me memorized.
Select the desired projector via the respective projector select button.
Adust the desired function via the channel faders.
Page Select-button:
Via the Page Select-button, you can adjust the channel faders from CH 1-8 to CH 9-16.
Display-button:
Via the Display-button, you can switch the display of the faderway from DMX-value (0-255) to procent (0-
100).

6.2 Programming

A program is a sequence of different scenes that will be called up one after another. With the DMX Scan
Control, you can program up to 30 different programs (banks) with up to 8 scenes each.
ONLY X/Y
FD TIME
Only Pan/Tilt
