Summary of Contents for Samsung SCD-6023R

  • Page 1 High Resolution Dome Camera User Manual SCD-6023R...
  • Page 2: User Manual

    Disclaimer Samsung makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility.
  • Page 3 Before operating the camera, confirm the camera model and correct input power voltage. To help you understand this manual thoroughly, we'll introduce our model description. ■ SCD-6023R SERIES • NTSC MODEL • PAL MODEL SCD-6023RN SCD-6023RP ■ MODEL DESCRIPTION • SCD-6023RX _ SIGNAL SYSTEM • SIGNAL SYSTEM...
  • Page 4 safety information CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates that dangerous voltage consisting a risk of electric shock is present within this unit.
  • Page 5 9. If this product fails to operate normally, contact the nearest service center. never disassemble or modify this product in any way. (samsung is not liable for problems caused by unauthorized modifications or attempted repair.) 10.
  • Page 6: Fcc Statement

    safety information FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : 1) This device may not cause harmful interference, and 2) This device must accept any interference received including interference that may cause undesired operation.
  • Page 7: Important Safety Instructions

    Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus Samsung cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products.
  • Page 8: Table Of Contents

    contents inTroDuCTion Features Components and Accessories Component names and functions insTallaTion Before installation Installation Adjusting the monitoring direction for the camera ConnECTion Connecting to Monitor Connecting to Power Using Coaxial Communications CamEra oPEraTion Menu Configuration Menu Setup TroublEshooTing Troubleshooting sPECifiCaTions Specifications Dimension 8_ contents...
  • Page 9: Introduction

    - Color : 0.45Lux (F2.1, 50IRE); 0.25Lux (F2.1, 30IRE) B/W : 0Lux(IR LED on) y ssnr4 (samsung super noise reduction) function High performance NVP2440H Chip removes noises of GAIN resulting from the low light level and shows a vivid, high definition video even in the dark place.
  • Page 10: Components And Accessories

    ComPonEnTs anD aCCEssoriEs Check if the following items are included in the product package. Super High Resolution WDR Dome Camera Quick Manual SCD-6023R SCD-6023R Quick Manual Screws Template 10_ introduction...
  • Page 11: Component Names And

    ComPonEnT namEs anD funCTions ➍ Dome Cover rotate base : control rotating angle of camera. lens module : 4mm (F2.1). function setup switch : Display the menu on the screen and move the cursor to four ➍ directions to confirm status or after changing a selected item. Pan base : Control panning angle of camera.
  • Page 12: Installation

    Installation bEforE insTallaTion Ensure you read out the following instructions before installing the camera: y You have to check whether the location (ceiling or wall) can bear five times the weight of your camera. y Don’t let the cable to be caught in improper place or the electric line cover to be damaged. Otherwise it may cause a breakdown or fire.
  • Page 13 installation 1. Attach the installation template to the selected area and punch 2 holes as shown in the figure. 케이블 구멍 2. Use the 2 supplied screws to fix the camera to the 2 punched holes. ` Set the <TOP FRONT> mark imprinted on the camera to face the direction of camera monitoring.
  • Page 14: Adjusting The Monitoring

    Installation aDJusTing ThE moniToring DirECTion for ThE CamEra Tilt Lens rotation ` Adjusting the monitoring direction You can adjust the camera direction only when the camera is fixed on the ceiling. Where, rotating the camera unit to the left or right is called Pan, adjusting the tilt is called Tilt, and turning the lens on its axis is called Rotation.
  • Page 15: Connection

    ConnECTing To moniTor Connect the Video OUT port on the rear panel of the camera to a AHD DVR. AHD DVR SCD-6023R Monitor y As the connecting method varies with the instruments, refer to the manual supplied with the instrument.
  • Page 16: Using Coaxial Communications

    connection When the resistance value of copper wire is at [20°C(68°F)] Copper wire size (AWG) #24 (0.22mm #22 (0.33mm #20 (0.52mm #18 (0.83mm Resistance value(Ω/m) 0.078 0.050 0.030 0.018 Voltage Drop (V/m) 0.028 0.018 0.011 0.006 y As shown in the table above, voltage decreases as the wire gets longer. Therefore use of an excessively long adaptor output line for connection to the camera may affect the performance of the camera.
  • Page 17 - Video Cable The camera's video output port is connected to the DVR with a BNC coaxial cable, shown below. Recommended Cable Distance Specification 500m 75-5 Coaxial Cable It is recommended that pure copper coax cable is used and not copper coated steel, as this will cause issues with the communication over the coaxial cable.
  • Page 18: Menu Setup

    camera operation mEnu ConfiguraTion main sETuP ● ● ● BASIC DAY/NIGHT BACKLIGHT PROFILE ● ● ● INDOOR USER ● ● D-WDR ● ● ● OUTDOOR INDOOR WHITE BAL ● ● AWC  SET MANUAL ● ● ● BRIGHTNESS SHUTTER EXPOSURE ●...
  • Page 19 MAIN SETUP Select the function ▶ 1. PROFILE BASIC Change the status using the Function using the Function 2. D-WDR Setup switch. Setup switch. 3. WHITE BAL 4. EXPOSURE 5. BACKLIGHT 6. SPECIAL 7. EXIT SAVE 1. Press the Function Setup switch. y Main SETUP menu is displayed on the monitor screen.
  • Page 20 camera operation y inDoor : It will be set automatically to help you take a picture in a regular indoor lighting condition. y usEr : Automatically configures the camera to your custom settings. 1) Select Custom for Simple Setup mode. 2) Configure the menu options to your custom settings.
  • Page 21 In D-WDR mode, there can be noise between a bright and dark area. Depending on light conditions, unnatural changes or symptoms can occur on the screen so deactivate the user mode. White bal (White balance) Use the White Balance function to adjust the screen color. 1.
  • Page 22 camera operation White Balance may not work properly under the following conditions. In this case select the AWC mode. Select this When the color temperature of environment surrounding the subject is out of the control range (e.g. clear sky, or sunset) When the ambient illumination of the subject is dim.
  • Page 23 When adjusting the noise reduction level in the SSNR4 mode, remember that the higher the level set, the more the noise level will be reduced, as will the brightness of the image. baCKlighT The camera uses our own NVP2440H chips that are designed to clearly display the object and the background despite severe reverse light.
  • Page 24 camera operation sPECial 1. When the SETUP menu screen is displayed, select ‘SPECIAL’ by using the Function Setup switch so that the arrow indicates ‘SPECIAL’. 2. Select a desired mode using the SPECIAL SETUP Function Setup switch. DISPLAY ▶ 1. y DisPlaY COMM ADJ IMAGE ADJ...
  • Page 25: Image Adj

    - FONT COLOR : You can change the OSD font color. (White, Yellow, Green, Red, Blue) - LANGUAGE : You can select the menu language according to your requirements. - RETURN : Return to the SPECIAL menu. y Comm aDJ (Communication adjustment) : - COAX : You can select whether to COMM SETUP use COAX communication.
  • Page 26 camera operation y ViDEo ouTPuT ❶ M If the SPECIAL menu screen is displayed, use the Function Setup switch so that the arrow indicates ‘VIDEO OUTPUT’. ❷MM S elect a desired mode using the Function Setup switch. - HD : HD Video resolution(1920X1080) - SD : SD Video resolution Please exit the menu and hold the “function setup switch”...
  • Page 27 y DEfog :  Y ou can use the defog mode to allow the camera to automatically detect the fog density of the screen and display a clear image despite smog, fog or general poor visibility. ❶ MM I f the SPECIAL menu screen is DEFOG displayed, use the Function Setup LEVEL...
  • Page 28 camera operation y moTion : This product generates signals each time an object movement is detected in the four areas of the screen so efficient monitoring can be achieved. ❶ MM I f the SPECIAL menu screen is MOTION DET displayed, use the Function Setup AREA ▶...
  • Page 29 troubleshooting TroublEshooTing If you have trouble operating your camera, refer to the following table. If the guidelines do not enable you to solve the problem, contact an authorized technician. Problems Troubleshooting Nothing appears on the screen. y Check that the power cord and line connection between the camera and monitor are properly connected.
  • Page 30 specifications sPECifiCaTions sCD-6023rn sCD-6023rP Video 1/2.9” 2M CMOS Imaging Device Total Pixels 2,000(H) x 1,121(V) 2.24M pixels Effective Pixels 1,984(H) x 1,105(V) 2.19M pixels Scanning System Progressive Scan Horizontal Resolution 1000TVL Color : 0.45Lux (F2.1, 50IRE); 0.25Lux (F2.1, 30IRE) Min. Illumination B/W : 0Lux(IR LED on) S / N Ratio 52dB (AGC off, Weight on)
  • Page 31 sCD-6023rn sCD-6023rP Off / On(4 zones) Motion Detection Off / On (4 zones rectangle) Privacy Masking Gain Control Off / Low / Middle / High / Very High White Balance ATW / Outdoor / Indoor / Manual / AWC(1,800K° ~ 10,500K°) Electronic Shutter 1 sec ~ 1/12,000 sec Speed...
  • Page 32: Dimension

    DimEnsion Unit: mm (inch) 32_ specifications...
  • Page 33 MEMO...
  • Page 34 6, Pangyo-ro 319beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, SEOUL 463-400 Rep. of KOREA Tel : +82-70-7147-8753, 8764 Fax : +82-31-8018-3740 www.samsungsecurity.com SAMSUNG TECHWIN AMERICA Inc. SAMSUNG TECHWIN EUROPE LTD. 100 Challenger Rd. Suite 700 Ridgefield Park, NJ 07660 2nd Floor, No. 5 The Heights, Brooklands, Weybridge, Surrey,...
