SCC-CO20 Module Pin Assignments
1 Pin 1
SCC-CO20 Isolated Current Output Module User Guide
Figure 7 shows the I/O connector pins on the bottom of the module.
2 Pin 2 3
Table 1 lists the signal connection corresponding to each pin.
Pin Number
1
2
3
4
5
6
7
8
9
10
11
12
13
4
5
PWB Key 4
Figure 7. SCC-CO20 Bottom View
Table 1. SCC-CO20 Pin Signal Connections
14
3
Pin 19 5 Pin 20
Signal
E/M Series AO (X)
E/M Series AO GND
—
E/M Series AO GND
—
—
—
—
+5 V
GND
—
+5 V REF
+15 V
1
2
