Saunier Duval Clima, S.A.
INSTALLATION MANUAL
SDCE/HE 050 D/K/F
SDCE/HE 065 D/K/F
SDCE/HE 085 D/K/F
SDCE/HE 105 D/K/F
SDCE/HE 105T D/K/F
SDCE/HE 130 D
SDHE 180 D
SDHE 230 D
Safety Regulations ............................................. 3
Indoor Units Installation and Dimensions
Ducted ........................................................... 4 - 5
Cassette ........................................................ 6 - 8
Ceiling-Floor ................................................ 9 - 10
Installation ..................................................11 - 12
Outdoor Units Dimensions .........................13 - 14
Wiring Diagrams ............................................... 15
Control Units Diagrams ..............................16 - 18
www.saunier-duval.co.uk
2003
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Saunier Duval SDHE 050 D
Summary of Contents for Saunier Duval SDHE 050 D
-
Page 1: Table Of Contents
Saunier Duval Clima, S.A. INSTALLATION MANUAL SDCE/HE 050 D/K/F SDCE/HE 065 D/K/F SDCE/HE 085 D/K/F SDCE/HE 105 D/K/F SDCE/HE 105T D/K/F SDCE/HE 130 D SDHE 180 D SDHE 230 D Safety Regulations ..........3 Indoor Units Installation and Dimensions Ducted ............4 - 5 Cassette ............ -
Page 3: Safety Regulations
4. The appliance is to be installed, maintained and repai- 15. Always use original Saunier Duval spare parts. Do not red by qualified staff pursuant to the demands of the use components removed from defective refrigeration guidelines, current regulations not to mention the trai- appliances as replacements. -
Page 4: Ducted
2- INDOOR UNIT INSTALLATION 2.1 DUCTED: INDOOR UNIT 2.1.3 INDOOR UNIT INSTALLATION 2.1.1 INITIAL CHECK - Insert and screw down a nut on each supporting rod. - Install indoor unit allowing for enough clearance around - Lift the indoor unit and insert the rods in the holes pro- the unit so there is room for handling and maintenance vided on the mounting brackets. - Page 5 2- INDOOR UNIT INSTALLATION 2.1.6 INDOOR UNIT DIMENSIONS (EDI) MODELS Conec. 050 EDI 1.000 1.040 Weld 065 EDI 1.000 1.040 Weld 085 EDI 1.010 1.050 Weld 105 EDI 1.210 1.100 1.150 1.250 Weld 130 EDI 1.315 1.100 1.150 1.355 Weld 180 EDI 1.400 1.047...
-
Page 6: Cassette
2- INDOOR UNIT INSTALLATION 2.2 CASSETTE: INDOOR UNIT 2.2.1 Install the indoor unit in a position: - Having sufficient strength to carry the weight of the indoor unit. - Where the inlet and outlet grilles are not obstructed and the conditioned air is able to blow all over the room. - From where pipes can be easily run to the outdoor unit. - Page 7 2- INDOOR UNIT INSTALLATION - Using level guide, line up the unit with a spirit level, and keep dimension between the fiber glass body and the lower part of the false ceiling. - Line up the unit to the supporting bars of the false ceiling tightening the nuts and counternuts of the threaded rods. - After connection of the condensate drain piping and piping connections, check again that the unit is level.
-
Page 8: Cassette
2- INDOOR UNIT INSTALLATION 2.2.4 FRESH AIR RENEWAL AND BRANCH DUCTING - The side opening allows separate ductwork to be installed for outside air intake and branch ducting. - Cut and remove anti-condensate insulating material. - Install your flanges and conduits to casing. Conduits can be flexible polyester with spring core or corrugated aluminum externally coated (dia.4 in.) with anti-condensate material (fiberglass 12-25 mm thickness). -
Page 9: Ceiling-Floor
2- INDOOR UNIT INSTALLATION 2.3 CEILING-FLOOR: INDOOR UNIT A.2 INSTALLING DRAIN HOSE 2.3.1 INSTALLATION PROCEDURE Be sure to arrange the drain hose so that it is levelled A. PREPARING INDOOR UNIT INSTALLATION lower than the drain port of the indoor unit. Remove the intake grille and side cover(s) by removing... - Page 10 2- INDOOR UNIT INSTALLATION B.2 DRILLING HOLES FOR ANCHOR BOLTS B.4 INSTALLING INDOOR UNIT AND INSTALLING THE ANCHOR BOLTS Reset the bolts as shown below. With a concrete drill, Apply the indoor unit to drill four 3/8” (9,5 mm) hangers. dia.
-
Page 11: Installation
3- INSTALLATION 3.1. OUTDOOR UNIT 3.2 Pipe connection (1) Install de outdoor unit in a place where it will be free from being dirty or getting by rain as much as possible. (2) During heating operation, drain water flows from the Installation Details outdoor unit. -
Page 12: Installation
3- INSTALLATION 3.7 POWER 3.4 CHECKING THE PIPE CONNECTIONS FOR GAS LEAKING (1) The rate voltage of this product is monophase (230V/1Ph/50 Hz) or triphase (400V/3Ph/50Hz). - For both the indoor and outdoor unit sides, check the (2) Perform wiring work in accordance with standards so joints for gas leaking by the use of a gas leakage that the room air conditioner can be operated safely detector without fail when the pipes are connected. -
Page 13: Outdoor Units Dimensions
4- OUTDOOR UNIT DIMENSIONS 4.1 OUTDOOR UNIT DIMENSIONS Model Models 050 - 065 Liq. 3/8" 050 / 065 Liq. 3/8" 3/4" 5/8" Models 105 / 105T / 130 105 - 105T Liq. 3/8" 1/2" 3/4" 3/4" Model Liq. 1/2" 7/8"... -
Page 14: Outdoor Units Dimensions
4- OUTDOOR UNIT DIMENSIONS 4.1 OUTDOOR UNIT DIMENSIONS Model Liq. 5/8" 1 1/8" Units in mm. 4.2 OUTDOOR UNIT LOCATION Units in mm. Units in mm. Location for a correct air flow... -
Page 15: Wiring Diagrams
5- WIRING DIAGRAMS 105T / 130 / 180 050 / 065 / 085 / 105 PAD WIRING DIAGRAM Heat Pump Option Hour SERIES 2003 Auto Cool Heat Fan Prog. Cooling Only Option Hour Cool Prog The installation of electric assault to the machine should have a Bipolar or Tetrapolar switch according to machine model, (mono- phase or treephase), of at least 3 mm of separation among contacts (norm EN-60335-2-40). - Page 16 6- CONTROL UNITS DIAGRAMS 6.1 DUCTED INDOOR UNITS Heater Relay Deflector Relay ON-OFF Switch Conn. 4-Way Valve Relay M-L-H Fan Relay TFULL Inner Jumper Float Outdoor Unit Fan Relay COMP Compressor Relay ROOM Room Temp. Sensor Condensation Pump Relay Fuse I.
-
Page 17: Control Units Diagrams
6- CONTROL UNITS DIAGRAMS 6.3 CEILING-FLOOR INDOOR UNITS Heater Relay Deflector Relay ON-OFF Switch Conn. 4-Way Valve Relay M-L-H Fan Relay TFULL Inner Jumper Float Outdoor Unit Fan Relay COMP Compressor Relay ROOM Room Temp. Sensor Condensation Pump Relay Fuse I. - Page 18 6- CONTROL UNITS DIAGRAMS 6.5 OUTDOOR UNITS 085 ECO/EHO 230 w 230 w 230 w CON1 CON2 CON3 R S T VDR2 VDR1 TRC1 TRC1 TRC3 TRC2 PRESOS. TERMOS. V.4.V. LED2 LED3 LED4 LED5 LED1 IC10 LED6 LED7 LED8 BOBINA TEST V.4.V.
