HEADSET OPTIONS

The Addict Disc/Gravel/CX features a tapered head tube and fork system.
The fork steerer is a 1 1/8" to 1 1/2".
241901 Headset Syncros Drop-In 1-1/8" - 1-1/2"
•

SEAT POST/CLAMP

The diameter of the seat post is 27.2mm. Please be aware to just use seat clamps with the
size of 30.2mm which fit the frame.
235429 Seatclamp 30.2mm bolt Addict MY14
| 06 ENGLISH
ADDICT DISC/GRAVEL/CX | 2016 BIKE USER MANUAL
•

BB STANDARDS/FD MOUNTING DETAILS

The Addict Disc/Gravel/CX is constructed with a Shimano press fit 86 bottom bracket. The
diameter of the cartridge is 41mm
The chain guide from the two-by shifting system is the same as the one from the SCOTT
Scale # 219578, for the front derailleur (FD) hanger use the part# 242435
219578 Chainguide System Scale 2011
242435 Chainguide set Addict CX '16
In case of a one-by shifting system the chain catcher is included in the same kit as the FD
hanger. Part# 242435
242435 Chainguide set Addict CX '16
2016 BIKE USER MANUAL | ADDICT DISC/GRAVEL/CX
Chainguide set Addict CX '16
Chainguide System Scale 2011
Chainguide set Addict CX '16
ENGLISH 07 |
