Page 1: Dome Camera
High Resolution Vandal-Resistant Dome Camera User Manual SCV-6083R... -
Page 2: User Manual
Disclaimer Samsung makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility. - Page 3 Before operating the camera, confirm the camera model and correct input power voltage. To help you understand this manual thoroughly, we'll introduce our model description. ■ SCV-6083R SERIES • NTSC MODEL • PAL MODEL SCV-6083RN SCV-6083RP ■ MODEL DESCRIPTION • SCV-6083RX _ SIGNAL SYSTEM •...
-
Page 4: Be Sure To Use Only The Standard Adapter That Is Specifi Ed In The Specifi Cation Sheet
safety information CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE CAUTION: COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates that dangerous voltage consisting a risk of electric shock is present within this unit. -
Page 5: Personal Injury
fi re or electric shock. If this product fails to operate normally, contact the nearest service center. never disassemble or modify this product in any way. (samsung is not liable for problems caused by unauthorized modifi cations or attempted repair.) When cleaning, do not spray water directly onto parts of the product. -
Page 6: Fcc Statement
safety information FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : This device may not cause harmful interference, and This device must accept any interference received including interference that may cause undesired operation. -
Page 7: Warning
Apparatus shall not be exposed to dripping or splashing and no objects fi lled with liquids, such as vases, shall be placed on the apparatus Samsung cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products. -
Page 8: Table Of Contents
contents INTRODUCTION Features Components and Accessories Component names and functions INSTALLATION Before installation Installation Adjusting the monitoring direction for the camera CONNECTION Connecting to Monitor Connecting to Power Using Coaxial Communications CAMERA OPERATION Menu Confi guration Menu Setup TROUBLESHOOTING Troubleshooting SPECIFICATIONS Specifi... -
Page 9: Features
- Color : 0.2Lux (F1.4, 50IRE); 0.11Lux (F1.4, 30IRE) B/W : 0Lux(IR LED on) SSNR4 (Samsung Super Noise Reduction) Function High performance NVP2440H Chip removes noises of GAIN resulting from the low light level and shows a vivid, high defi nition video even in the dark place. -
Page 10: Components And Accessories
COMPONENTS AND ACCESSORIES Check if the following items are included in the product package. High Resolution WDR Vandal-Resistant Dome Camera Quick Manual SCV-6083R SCV-6083R Quick Manual Screws Card-type moisture Template L Wrench ➊ absorbent ➋ ➌ ➍ ➎ ➏... -
Page 11: Component Names And Functions
COMPONENT NAMES AND FUNCTIONS ➌ ➋ ❿ ⓫ ➊ ➍ ➎ ➏ ➐ ➑ ➒ ➊ Dome Cover ➋ Rotate base : control rotating angle of camera. ➌ Vari-focal Lens Module : 2.8 ~ 12mm (F1.4). ➍ Function Setup switch : Display the menu on the screen and move the cursor to four directions to confirm status or after changing a selected item. -
Page 12: Installation
Installation BEFORE INSTALLATION Ensure you read out the following instructions before installing the camera: You have to check whether the location (ceiling or wall) can bear fi ve times the weight of your camera. Don’t let the cable to be caught in improper place or the electric line cover to be damaged. Otherwise it may cause a breakdown or fi... - Page 13 Installing the camera on a ceiling or wall Drill holes on the ceiling by matching to the holes on the case bed, and insert plastic anchors (HUD 5) (not included) fully into the holes. Fix the case bed on the ceiling by using screws . (3 places) screw Connect Power and video cables and arrange them through the hole you want to pass when mounting the main body on the mounting bracket, note that not to...
- Page 14 Installation Adjust the lens in a desired direction by referring to the “Adjusting the monitoring direction for the camera”section. Close the dome cover. To ensure waterproofi ng, tight up the fi xing bolts using the L-wrench. Dome cover The installation should be done by qualifi...
-
Page 15: Adjusting The Monitoring
ADJUSTING THE MONITORING DIRECTION FOR THE CAMERA Tilt Lens rotation Adjusting the monitoring direction You can adjust the camera direction only when the camera is fi xed on the ceiling. Where, rotating the camera unit to the left or right is called Pan, adjusting the tilt is called Tilt, and turning the lens on its axis is called Rotation. -
Page 16: Connection
CONNECTING TO MONITOR Connect the Video OUT port on the rear panel of the camera to a AHD DVR. AHD DVR SCV-6083R Monitor As the connecting method varies with the instruments, refer to the manual supplied with the instrument. -
Page 17: Using Coaxial Communications
When the resistance value of copper wire is at [20°C(68°F)] Copper wire size (AWG) #24 (0.22mm #22 (0.33mm #20 (0.52mm #18 (0.83mm Resistance value(—/m) 0.078 0.050 0.030 0.018 Voltage Drop (V/m) 0.028 0.018 0.011 0.006 As shown in the table above, voltage decreases as the wire gets longer. Therefore use of an excessively long adaptor output line for connection to the camera may affect the performance of the camera. - Page 18 connection Video Cable The camera's video output port is connected to the DVR with a BNC coaxial cable, shown below. Recommended Cable Distance Specification 500m 75-5 Coaxial Cable It is recommended that pure copper coax cable is used and not copper coated steel, as this will cause issues with the communication over the coaxial cable.
-
Page 19: Camera Operation
camera operation MENU CONFIGURATION MAIN SETUP ● ● ● BASIC DAY/NIGHT BACKLIGHT PROFILE ● ● ● INDOOR USER ● ● D-WDR ● ● ● OUTDOOR INDOOR WHITE BAL ● ● AWC MANUAL ● ● ● BRIGHTNESS LENS SHUTTER EXPOSURE ● ●... - Page 20 camera operation MAIN SETUP Select the function 1. PROFILE BASIC Change the status using the Function using the Function 2. D-WDR Setup switch. Setup switch. 3. WHITE BAL 4. EXPOSURE 5. BACKLIGHT 6. SPECIAL 7. EXIT SAVE Press the Function Setup switch. Main SETUP menu is displayed on the monitor screen.
- Page 21 INDOOR : It will be set automatically to help you take a picture in a regular indoor lighting condition. USER : Automatically confi gures the camera to your custom settings. Select Custom for Simple Setup mode. Configure the menu options to your custom settings. The settings are automatically saved as Custom mode.
- Page 22 camera operation In D-WDR mode, there can be noise between a bright and dark area. Depending on light conditions, unnatural changes or symptoms can occur on the screen so deactivate the user mode. White Bal (White Balance) Use the White Balance function to adjust the screen color. When the SETUP menu screen is displayed, select ‘White Bal’...
- Page 23 White Balance may not work properly under the following conditions. In this case select the AWC mode. ➊ Select this When the color temperature of environment surrounding the subject is out of the control range (e.g. clear sky, or sunset) ➋...
- Page 24 camera operation The greater the shutter value the brighter the screen is but the more the residual images of objects there are. If the min shutter value is large, it can cause noise, spots and white areas but still operate normally. ...
- Page 25 HLC (High Light Compensation) : HLC SETUP This function masks the strong light LEVEL MIDDLE to minimize white out due to over LIMIT NIGHT ONLY exposure and preserve much of the IIIIIIIIII IIIIIIIIII on-screen details when the camera BOTTOM IIIIIIIIII IIIIIIIIII aims a strong light source.
- Page 26 camera operation SPECIAL When the SETUP menu screen is displayed, select ‘SPECIAL’ by using the Function Setup switch so that the arrow indicates ‘SPECIAL’. Select a desired mode using the SPECIAL SETUP Function Setup switch. DISPLAY DISPLAY COMM ADJ ❶ IMAGE ADJ If the SPECIAL menu screen is displayed, use the Function Setup...
- Page 27 FONT COLOR : You can change the OSD font color. (White, Yellow, Green, Red, Blue) LANGUAGE : You can select the menu language according to your requirements. RETURN : Return to the SPECIAL menu. COMM ADJ (Communication Adjustment) : COAX : You can select whether to COMM SETUP use COAX communication.
- Page 28 camera operation VIDEO OUTPUT ❶ If the SPECIAL menu screen is displayed, use the Function Setup switch so that the arrow indicates ‘VIDEO OUTPUT’. ❷ Select a desired mode using the Function Setup switch. HD : HD Video resolution(1920X1080) SD : SD Video resolution ...
- Page 29 DEFOG : You can use the defog mode to allow the camera to automatically detect the fog density of the screen and display a clear image despite smog, fog or general poor visibility. ❶ If the SPECIAL menu screen is DEFOG displayed, use the Function Setup LEVEL...
- Page 30 camera operation MOTION : This product generates signals each time an object movement is detected in the four areas of the screen so efficient monitoring can be achieved. ❶ If the SPECIAL menu screen MOTION DET is displayed, use the Function 1.
-
Page 31: Troubleshooting
troubleshooting TROUBLESHOOTING If you have trouble operating your camera, refer to the following table. If the guidelines do not enable you to solve the problem, contact an authorized technician. Problems Troubleshooting Nothing appears on the screen. Check that the power cord and line connection between the camera and monitor are properly connected. -
Page 32: Specifications
specifications SPECIFICATIONS SCV-6083RN SCV-6083RP Video Imaging Device 1/2.9” 2M CMOS Total Pixels 2,000(H) x 1,121(V) 2.24M pixels Effective Pixels 1,984(H) x 1,105(V) 2.19M pixels Scanning System Progressive Scan Horizontal Resolution 1000TVL Color : 0.2Lux (F1.4, 50IRE); 0.11Lux (F1.4, 30IRE) Min. Illumination B/W : 0Lux(IR LED on) S / N Ratio 52dB (AGC off, Weight on) - Page 33 SCV-6083RN SCV-6083RP Defog AUTO / MANUAL / OFF Motion Detection Off / On(4 zones) Privacy Masking Off / On (4 zones rectangle) Gain Control Off / Low / Middle / High / Very High White Balance ATW / Outdoor / Indoor / Manual / AWC(1,800K° ~ 10,500K°) Electronic Shutter 1 sec ~ 1/12,000 sec Speed...
-
Page 34: Dimension
DIMENSION Unit: mm (inch) 34_ specifi cations... - Page 35 MEMO...
