Samsung SCV-3120 User Manual

Samsung SCV-3120 User Manual

Vandal-resistant wdr dome camera
Hide thumbs Also See for SCV-3120:
Table of Contents

Advertisement

Quick Links

Download this manual
SCV-3120
VANDAL-RESISTANT
WDR DOME CAMERA

User Manual

imagine
the possibilities
Thanks you for purchasing this Samsung product.
To receive a more complete service, please visit
our website
www.samsungsecurity.com
809126301A-SCV-3120-PAL-ENG.in1 1
2010-4-30 17:37:0

Advertisement

Table of Contents
loading

Related Manuals for Samsung SCV-3120

Summary of Contents for Samsung SCV-3120

  • Page 1: User Manual

    SCV-3120 VANDAL-RESISTANT WDR DOME CAMERA User Manual imagine the possibilities Thanks you for purchasing this Samsung product. To receive a more complete service, please visit our website www.samsungsecurity.com 809126301A-SCV-3120-PAL-ENG.in1 1 2010-4-30 17:37:0...
  • Page 2 Do not connect multiple cameras to a single adapter. Exceeding the capacity may cause abnormal heat generation or fire. Securely plug the power cord into the power receptacle. Insecure connection may cause fire. _ overview 809126301A-SCV-3120-PAL-ENG.in2 2 2010-4-30 17:37:0...
  • Page 3 Continued use in such a condition may cause fire or electric shock. If this product fails to operate normally, contact the nearest service center. Never disassemble or modify this product in any way. (SAMSUNG is not liable for problems caused by unauthorized modifications or attempted repair.) When cleaning, do not spray water directly onto parts of the product.

  • Page 4: Fcc Statement

    IC Compliance Notice This Class A digital apparatus meets all requirements of the Canadian Interference.-Causing Equipment Regulations of ICES-003. _ overview 809126301A-SCV-3120-PAL-ENG.in4 4 2010-4-30 17:37:0...

  • Page 5: Important Safety Instructions

    Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus English _ 809126301A-SCV-3120-PAL-ENG.in5 5 2010-4-30 17:37:0...

  • Page 6: Table Of Contents

    At a Glance installation & Connecting with other Device Installation connection Optional Accessories for Installation camera setup Main Menu Profile Camera Setup Intelligent Video Privacy Zone Preset Other Set Communication System Info appendix Shortcut Keys Specifications _ overview 809126301A-SCV-3120-PAL-ENG.in6 6 2010-4-30 17:37:0...

  • Page 7: Product Features

    (optional) without additional cabling. ※ Coaxial Controller (Option) Intelligent video (moved/Fixed)  This Camera provides built-in capability for video content analysis. Operational modes include fixed mode (appear the object) and moved mode (disappear the object). English _ 809126301A-SCV-3120-PAL-ENG.in7 7 2010-4-30 17:37:0...

  • Page 8: What's Included

    Used to stop up a hole. Tapping TH, M4xL30. Used for ceiling and wall installations Screws BLACK +O RING Used for assembling / disassembling the dome L-wrench TORX T-20 cover. _ overview 809126301A-SCV-3120-PAL-ENG.in8 8 2010-4-30 17:37:1...

  • Page 9: At A Glance

    It contains RS-485 communication jack, Day/Night In jack, Alarm in and Function Jack Alarm out jack. Wipe out a dirty surface of the lens softly with a lens tissue or cloth to which you have applied ethanol. English _ 809126301A-SCV-3120-PAL-ENG.in9 9 2010-4-30 17:37:1...
  • Page 10 To separate the bracket from the main unit for the installation or to separate the Lock Release camera from an installed camera, push this release and turn the main unit in the marked direction of <UNLOCK>. 10_ overview 809126301A-SCV-3120-PAL-ENG.in10 10 2010-4-30 17:37:1...

  • Page 11: Connecting With Other Device

    This is a function to receive the external DAY/NIGHT signal from the DAY/NIGHT IN: sensor(option) and convert the signal into BW. RS-485 DATA-: Jack for connection to RS-485 DATA- signal line. RS-485 DATA+: Jack for connection to RS-485 DATA+ signal line. English _11 809126301A-SCV-3120-PAL-ENG.in11 11 2010-4-30 17:37:1...
  • Page 12 LENS The requirements for RS485 control is as follows : - Signaling Speed: 9600 bps - Data Bit : 8 bits - Stop Bit : 1 bit - Parity Bit : none 1_ installation & connection 809126301A-SCV-3120-PAL-ENG.in12 12 2010-4-30 17:37:1...

  • Page 13: Installation

    WALL MOUNT ADAPTOR(SCX-300WM)/ HANGING MOUNT(SCX-300HM) This adaptor is used when installing the dome camera onto a wall. CEILING MOUNT ADAPTOR(SCX-300CM)/ HANGING MOUNT(SCX-300HM) This adaptor is used when installing the dome camera on a concrete ceiling. English _1 809126301A-SCV-3120-PAL-ENG.in13 13 2010-4-30 17:37:1...
  • Page 14 This is an adaptor for WALL MOUNT ADAPTOR (SCX-300WM) installation on the corner of wall joint. Installing on the ceiling directly Using the L-wrench provided, loosen 3 screws by turning them counterclockwise and separate the dome cover. 1_ installation & connection 809126301A-SCV-3120-PAL-ENG.in14 14 2010-4-30 17:37:2...
  • Page 15 Adjust the lens aiming to your desired direction. Assemble the Dome Cover. For waterproof purpose, fix and secure the bolt using L-wrench provided. English _1 809126301A-SCV-3120-PAL-ENG.in15 15 2010-4-30 17:37:2...
  • Page 16 Tapping Screws (TH, M4xL30) by matching the fixing holes (3 places). Assemble the Dome Cover. Refer tot the step 6 of “Installing on the ceiling directly". 1_ installation & connection 809126301A-SCV-3120-PAL-ENG.in16 16 2010-4-30 17:37:2...
  • Page 17 PCB. Assemble the camera module and the case. Refer tot the step 4 of “Installing on the ceiling directly". Adjust the lens aiming to your desired direction and assemble the dome cover. English _1 809126301A-SCV-3120-PAL-ENG.in17 17 2010-4-30 17:37:3...
  • Page 18 "Tilting". For panning, the panning limit is 220° for the clockwise, and 120° for the counterclockwise, a total of 340° enabled; further rotation is stopped by the stopper. Tilting ranges from 0° to 90°. When it's closed to horizontal level, the screen display may become obscure. 1_ installation & connection 809126301A-SCV-3120-PAL-ENG.in18 18 2010-4-30 17:37:3...

  • Page 19: Main Menu

    You can reset the camera, or adjust the OSD color to your preference. CommUNICATIoN  Configures the settings pertaining to RS-485 communication. SySTem INFo  Shows the system information such as the camera version or communication set- tings. English _1 809126301A-SCV-3120-PAL-ENG.in19 19 2010-4-30 17:37:3...
  • Page 20 This automatically configures the settings so that you can work in a stable illumination condition as indoors. CUSTom  Your change to any of the PROFILE settings will switch the display to CUSTOM. 0_ camera setup 809126301A-SCV-3120-PAL-ENG.in20 20 2010-4-30 17:37:3...
  • Page 21 SeNSe Up MEDIUM MEDIUM MEDIUM MEDIUM MEDIUM AUTO AUTO AUTO NIGHT BURST dAy/NIGHT BURST DAY/NIGHT DAY/NIGHT mode ATW2 ATW1 ATW1 ATW1 ATW1 BLUe WHITe BAL NIGHT BRIGHTNeSS MEDIUM MEDIUM mode ATW2 ATW2 BLUe deTAIL English _1 809126301A-SCV-3120-PAL-ENG.in21 21 2010-4-30 17:37:3...
  • Page 22  the camera ID. When done, press [ENTER]. The camera ID will be displayed in the specified position. If you set it to <oN>, the camera images will be displayed in progressive mode. _ camera setup 809126301A-SCV-3120-PAL-ENG.in22 22 2010-4-30 17:37:3...
  • Page 23 MANUAL : Adjust the iris level manually.  The overall brightness target of a camera will be set to [ 00 ] ----I---- LEVEL ALC level 0, while the iris can be adjusted manually. English _ 809126301A-SCV-3120-PAL-ENG.in23 23 2010-4-30 17:37:3...
  • Page 24 As long as DAY/NIGHT is set to <AUTO>, the <MOTION> menu is not available. Reduces the noise on the camera image. The higher the level is, the greater the effect is. Set it to <USeR> to specify the level. _ camera setup 809126301A-SCV-3120-PAL-ENG.in24 24 2010-4-30 17:37:3...
  • Page 25 This will correct a brightness difference between different scenes for the optimal visibility by calculating the ambient luminance contrast in a certain unit of pixels. The higher the value is, the higher the correction level is. English _ 809126301A-SCV-3120-PAL-ENG.in25 25 2010-4-30 17:37:3...
  • Page 26 Any excessively bright area in a night scene will be MASKed. You can specify MASK 1 and 2 simultaneously. _ camera setup 809126301A-SCV-3120-PAL-ENG.in26 26 2010-4-30 17:37:3...

  • Page 27: White Bal

    <ATW2> mode.  2 : With <ATW2> mode active in a mostly single color environment, the display color and the actual one may differ; so select a mode as appropriate to your color temperature environment. English _ 809126301A-SCV-3120-PAL-ENG.in27 27 2010-4-30 17:37:3...
  • Page 28 BRIGHTNESS : Specify a brightness level switching from DAY mode to NIGHR mode setting. RED : Adjust the strength of the red color. BLUE : Adjust the strength of the blue color. R-GAIN/B-GAIN : Specify the current color temperature manually. _ camera setup 809126301A-SCV-3120-PAL-ENG.in28 28 2010-4-30 17:37:3...

  • Page 29: Focus Mode

    You can adjust the zoom operation speed. dISpLAy Zoom You can set to display the zoom status on the screen. It will disappear in about 3 seconds if the zoom factor has no further change. English _ 809126301A-SCV-3120-PAL-ENG.in29 29 2010-4-30 17:37:3...

  • Page 30: Digital Zoom

    If more than one PRIVACY ZONE is specified, and PRIVACY SET to <ON>, the PIP function is not available. As long as SENS-UP is set to FIXED, PIP menu is not available. According to the luminance, PIP will disappear if the SENS-UP menu is set to AUTO. 0_ camera setup 809126301A-SCV-3120-PAL-ENG.in30 30 2010-4-30 17:37:3...

  • Page 31: Intelligent Video

    In following situations, FIXED/MOVED detection may not work properly. - When multiple motions continue arbitrarily. - When the object that is fixed continues to move in the same position. - When a newly appearing object conceals another object that is moving. English _1 809126301A-SCV-3120-PAL-ENG.in31 31 2010-4-30 17:37:4...
  • Page 32 When selected <oN>, it displays the motion detected and detection of configured advanced function. SeNSITIvITy Sets the sensitivity of motion sensor. ReSoLUTIoN The bigger the resolution setting, the smaller the object that can be detected. _ camera setup 809126301A-SCV-3120-PAL-ENG.in32 32 2010-4-30 17:37:4...

  • Page 33: Privacy Zone

    Setting one or more privacy zone and enabling privacy function will disable the PIP function. For better privacy protection, make your privacy zone bigger than the required, bigger by about 30%. Video portion of mosaic pattern or colored by the privacy zone setup is not recoverable. English _ 809126301A-SCV-3120-PAL-ENG.in33 33 2010-4-30 17:37:4...

  • Page 34: Preset

    Select the preset number. PRESET   1 1/16   HOME RETURN Select <poSITIoN>. PRESET NO. 1 Set <PRESET ID> to <ON> and enter the POSITION name. PRESET ID For entering the name, refer to “CAMERA ID”. (page 22) _ camera setup 809126301A-SCV-3120-PAL-ENG.in34 34 2010-4-30 17:37:4...

  • Page 35: Other Set

    If MOTION and FIXED/MOVED option are set as on, FIXED/MOVED camera would send off alarm beep after detecting the ALARM moving object. Whenever there is alarm signal, camera would send off alarm beep if you set alarm as on. English _ 809126301A-SCV-3120-PAL-ENG.in35 35 2010-4-30 17:37:4...

  • Page 36: Communication

      Select <MAIN MENU>-<SYSTEM INFO>. 4 _ 12ZOM _ WDR _ P TYPE The current system information is displayed. PROTOCOL SAMSUNG-E ADDRESS COMM. TYPE RS485, HALF BAUD RATE 9600 SERIAL NO. 000000000000000 v1.00 _ 000000 CAMERA VER. _ camera setup 809126301A-SCV-3120-PAL-ENG.in36 36 2010-4-30 17:37:4...

  • Page 37: Shortcut Keys

    [PRESET] + [5] + [2] + [2] + [ENTER] Resetting (Factory Defaults) [PRESET] + [5] + [2] + [3] + [ENTER] Function CCD Defect Correction [PRESET] + [5] + [2] + [4] + [ENTER] English _ 809126301A-SCV-3120-PAL-ENG.in37 37 2010-4-30 17:37:4...

  • Page 38: Specifications

    0.7 Lux 0.07 Lux 30IRE 0.42 Lux 0.042 Lux Minimum subject 15IRE 0.21 Lux 0.021 Lux illumination x512 50IRE 0.00137 Lux 0.00014 Lux x512 30IRE 0.00082 Lux 0.00008 Lux x512 15IRE 0.00041 Lux 0.00004 Lux appendix 809126301A-SCV-3120-PAL-ENG.in38 38 2010-4-30 17:55:0...
  • Page 39 Zoom 1x ~ 16x ATW1/ATW2/AWC/MANUAL Mode White Balance (3200°K, 5600°K, R/B Gain adjustment) -10°C~+50°C Operation Temperature ~90% Operation Humidity Dimensions 160mm x 134.5mm x 160mm (WxHxd) approximately 1.5 kg Weight silver Product Color English _ 809126301A-SCV-3120-PAL-ENG.in39 39 2010-4-30 17:37:4...
  • Page 40 Part No.: Z6809126301A(REV 00) 809126301A-SCV-3120-PAL-ENG.in40 40 2010-4-30 17:48:0...
