Valor 1500INO Installation & Owner's Manual

L1 series dv zc gas fireplace for outdoor use
Hide thumbs Also See for 1500INO:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owners & Installation Manual
DV ZC Gas Fireplace for Outdoor use
1500INO (NG) & 1500IPO (LPG)
DANGER
!
A barrier designed to reduce the risk of burns from the hot
viewing glass is provided with this appliance and shall be
installed for the protection of children and other at-risk
individuals.
!
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
— Do not store or use gasoline or other
fl ammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
▪ Do not try to light any appliance.
▪ Do not touch any electrical switch; do
not use any phone in your building.
▪ Leave the building immediately.
▪ Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
▪ If you cannot reach your gas supplier,
call the fi re department.
— Installation and service must be
performed by a qualifi ed installer, service
agency or the gas supplier.
4005171-03
©2016, Miles Industries Ltd.
L1 S
Installation & Owner's Manual
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
ERIES
This manual contains instruc-
tions to install the ENGINE
ONLY. A front or trim kit is RE-
QUIRED to install the engine. A
barrier screen is provided with
the front or trim kit. Refer to
the manual supplied with the
front or trim for installation.
!
WARNING: FOR OUTDOOR USE ONLY.
!
WARNING:
adjust ment , alteration, ser vice or
maintenance can cause injury or property
damage. Read the installation, operating, and
maintenance instructions thoroughly before
installing or servicing this equipment.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certifi ed kit is used.
Massachusetts: The piping and fi nal
gas connection must be performed by a
licensed plumber or gas fi tter in the State of
Massachusetts. Also, see Carbon Monoxide
Detector requirements on page 13.
Ce guide est disponible en français sur demande.
Designed and Manufactured by
Miles Industries Ltd.
North Vancouver, BC, CANADA
www.valorfi replaces.com
I N S TA L L E R
L e a v e t h i s m a n u a l
w i t h t h e a p p l i a n c e .
C O N S U M E R
R e t a i n t h i s m a n u a l
f o r f u t u r e r e f e r e n c e .
Improper installation,
