1300IRN (NG) & 1300IRP (LPG)
!
WARNING
!
WARNING
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or loss of life.
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light the appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call
the fire department.
Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
4001746-11
©2010, Miles Industries Ltd.
V
ogue
Direct Vent
Zero Clearance Fireplace
Installation & Operating Instructions
WARNING
HOT GLASS WILL
HOT GLASS WILL
HOT GLASS WILL
CAUSE BURNS.
CAUSE BURNS.
CAUSE BURNS.
DO NOT TOUCH GLASS
DO NOT TOUCH GLASS
DO NOT TOUCH GLASS
UNTIL COOLED.
UNTIL COOLED.
UNTIL COOLED.
NEVER ALLOW CHILDREN
NEVER ALLOW CHILDREN
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
TO TOUCH GLASS.
TO TOUCH GLASS.
Manufactured by
MILES INDUSTRIES LTD., British Columbia, Canada
www.valorfireplaces.com
INSTALLER: Leave this manual
with the appliance.
CONSUMER: Retain this manual
for future reference.
Please read this manual BEFORE
installing and operating this
appliance.
This appliance may be installed in an
after-market permanently located,
manufactured (mobile) home where not
prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
This appliance is a domestic room-heating
appliance. It must not be used for any other
purposes such as drying clothes, etc.
This appliance is suitable for installation in a
bedroom or bed sitting room.
Massachusetts: The piping and final
gas connection must be performed by a
licensed plumber or gas fitter in the State of
Massachusetts. Also, see Carbon Monoxide
Detector requirements under "Safety and
Warning Information" on page 5.
