Instructions manual
01954
Video door entry unit with colour monitor, LCD 3.5"
for the DigiBus call system

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 01954 and is the answer not in the manual?

Questions and answers

Related Manuals for Vimar 01954

Summary of Contents for Vimar 01954

  • Page 1 Instructions manual 01954 Video door entry unit with colour monitor, LCD 3.5" for the DigiBus call system...

  • Page 3: Table Of Contents

    Table of Contents Technical characteristics ……………………………………………………………………………………………………………… 2 Type of system ……………………………………………………………………………………………………………………… 3 Advantages of the DigiBus system ……………………………………………………………………………………………… 4 Description of terminals …………………………………………………………………………………………………………… 4 Power input ………………………………………………………………………………………………………………………… 7 Operation of the ELVOX DigiBus system ………………………………………………………………………………………… 7 Compatible ELVOX power supplies ……………………………………………………………………………………………… 7 General information on the digital commands ……………………………………………………………………………………...

  • Page 4: Technical Characteristics

    (power supply, electric lock relay, etc.). Figure 1 - Video door entry unit 01954, 01954.14, 01954.20.

  • Page 5: Type Of System

    Technical characteristics Type of system. The video door entry unit can only be used on ELVOX video door entry systems of the DigiBus digital type. It will therefore be necessary to use solely ELVOX power supplies in the DigiBus range (for the specifications see the relevant ELVOX manuals).

  • Page 6: Advantages Of The Digibus System

    Technical characteristics Advantages of the DigiBus system. The most important advantage offered by the DigiBus system compared to a classic analogue video door entry system (8 wires + n) is the “saving” (on the pillar side) of the single call wire for each indoor station (necessary, on the contrary, in the classic analogue system).
  • Page 7 Technical characteristics The connector, pillar side, through which all the connections from and to the video door entry unit are made, has 16 terminals (inputs and outputs) divided according to the functions given in the following table: Terminal number Type Function Input/Output Digital line...
  • Page 8 Technical characteristics Figure 4 - Hooking onto the bracket Figure 5 - Unhooking from the bracket Figure 6 - Removing the video door entry unit...

  • Page 9: Power Input

    Technical characteristics Power input. The consumption of the video door entry unit depends on the current operating mode of the device (standby, on call, red/green LED on, control activation, etc.). The average values of the power input in the three typical operating modes are the following: - on standby 15 mA.

  • Page 10: General Information On The Digital Commands

    Technical characteristics General information on the digital commands The digital commands are data packets that can be sent by every digital device containing the information/in- structions that enable activating a particular function (unlocking, switching on stair lights, activating auxiliary func- tion, etc.) by means of an actuator.

  • Page 11: Functions Of The Video Door Entry Unit

    Functions of the video door entry unit The main function of the device is, by communicating over the audio and video channels, to identify anyone want- ing to enter the dwelling by using the outdoor station and to open the electrical lock of the gate or door when appropriate.

  • Page 12: Video Signal Cable Selector

    Functions of the video door entry unit Video signal cable selector. The selector on the back of the video door entry unit by the letters "DC", depending on the type of video signal used, permits selecting the most appropriate mode to reduce interference on this signal. The selector, shown in the figure with V1, permits two different settings depending on whether the video signal from the outdoor station is wired with coaxial cable (polarized video signal) or, alternatively, with a twisted pair (differential video signal).

  • Page 13: The "Second Function" (2Ndf) Button And Type Of Unit Outside The Door

    Functions of the video door entry unit The “Second Function” button (2ndF) and type of unit outside the door. Sending the main commands CALL-F1, CALL-F2 and LOCK is controlled by pressing the related buttons of the video door entry unit A, C and B. The system moreover enables sending additional commands of “auxiliary functions”...

  • Page 14: Numerical Code Of The Video Door Entry Unit

    Functions of the video door entry unit Button 2ndF, pressed in combination with other buttons, sends additional separate supplementary commands on the digital line ranging from CALL-F3 to CALL-F8. When the button C is configured as 2ndF the command – button correspondence is the following: LOCK Pressing button B CALL-F1...
  • Page 15 Functions of the video door entry unit Figure 12 Figure 11 • Using a screwdriver or small tool, briefly press the push-button R under button D (figure 11); • Press and hold down button B for at least 5 seconds (door-opening function) (figure 12); •...

  • Page 16: Call Answering

    Functions of the video door entry unit Call answering. When a call is made from an outdoor station (external plate or consumer unit), the video door entry unit related to the called numerical identification modulates the programmed call tone on the speaker; the video door entry unit then emits an audible warning and, if the video signal has been connected as well, the LCD monitor lights up to display the person calling.

  • Page 17: Door Open" Signal

    “Door open” signal powered with additional ELVOX power supply 6582 15 VA (13.5 V d.c.). Network Power supply Art. 6582 Video door entry unit 15/AS 01954 S/S1 01954.14 01954.20 Figure 13 - Connection of the “open door” V 1 3 4 5 - + C signal with additional power supply.

  • Page 18: Lock Command Activation

    Functions of the video door entry unit Lock control activation. This control activates the lock opening relay of the door or gate providing access to the dwelling. The command is carried out by pressing button B that sends the LOCK command to the plate which activates the lock opening relay in the power supply;...

  • Page 19: Auxiliary Function Activation

    Functions of the video door entry unit Auxiliary Function activation. The Auxiliary Function activation control can be used to activate external devices or services such as, for instance, courtesy lights, automation, etc.; this is possible by hooking up a suitable external relay at 12 V d.c. or 15 V a.c. and a contact that depends on the service you want to activate.

  • Page 20: Call Outside The Door

    9 and 5 on the 16-pin connector and setting the correct type of outside the door (see page 10). For more details see the “Main Configurations” and “Installation Examples” section. Example of installation AUDIO Configuration DOORBELL Configuration Video door Video door entry unit entry unit 01954 01954 01954.14 01954.14 01954.20 01954.20 Landing call button Push-button 20576 / 14576 1 P N.O.

  • Page 21: Installation Of Supplementary External Bells

    ELVOX external relay 170/101 and load at 230 V a.c. max 3 A. C 1 2 15 RC 3 4 5 Drum bell Video door entry unit Bell power supply 01954 01954.14 01954.20 Figure 17 - Installation of supplementary external bells.

  • Page 22: Installation Topology

    (for example video distribu- tors, supplementary power supplies, etc.). Figures 18 and 19 show the installation diagrams for the simplest configurations: Video door entry unit 01954 01954.14 01954.20 Video door entry unit 01954 01954.14...
  • Page 23 • additional power supplies (F); • video distributors (H) Both VIMAR and ELVOX (C) indoor stations can be installed in the pillar provided they belong exclusively to the DigiBus range. For the technical details on the possible installation topologies in both “simple” residential and in complex building...
  • Page 24 Installation topology Video door entry units pillar Video door entry units pillar Additional plate Figure 20 - Multiple outdoor station and Plates at the bottom of the stairs.

  • Page 25: Configuring The Video Door Entry Unit

    Configuring the vide door entry unit All the main functions of the video door entry unit seen in the “FUNCTIONS OF THE VIDEO DOOR ENTRY UNIT” chapter are configured using the buttons on the front of the device (see fig. 3). Depending on the operational status of the monitor (ON OR OFF) it is possible to set and program different functions that are as follows: Self-start function enabling.

  • Page 26: User Away" Function Enabling

    Configuring the vide door entry unit “User away” function enabling. This type of function allows the user, via the external plate, to signal his/her absence to the consumer unit (where applicable); in addition it can also be used when the user is present but does not want to be disturbed. When this function is enabled, the video door entry unit receiving the call emits no audible warning, but sends the “user away”...

  • Page 27: Activation Of Monitor Switch-On By Call From Outside The Door

    Configuring the vide door entry unit Activation of monitor switch-on by call from outside the door. If there is an outdoor station outside the door with a video camera, the video door entry unit must be configured so that on receiving a call the monitor switches on (besides obviously enabling the voice unit). To enable switching on the monitor from outside the door, with the MONITOR OFF, carry out the following opera- tions: •...

  • Page 28: Selecting Bell Type

    Configuring the vide door entry unit Selecting bell type. It is possible to select the types of bell to combine with the different calls that the video door entry unit can receive: - call from plate; - call from outside the door. Setting the plate bell.

  • Page 29: Video Parameter Adjustment

    Configuring the vide door entry unit Video parameter adjustment. With the following procedures it is possible to set the three parameters that govern the video picture on the LCD monitor: - brightness; - contrast; - colour. Setting brightness. To set the level of brightness of the LCD monitor, it is necessary, with the MONITOR ON, to carry out the following operations: •...

  • Page 30: Programming The Digibus Plate

    Programming the DigiBus plate WARNING! The following steps must be carried out after powering up the system and before programming the audio and video door entry units. The plate parameters can be configured in three different ways: • Directly from the plate using the alphanumeric keypad or single buttons. •...

  • Page 31: Example Of Plate Technical Parameters

    Example of plate technical parameters Abbreviation on the display Minimum Maximum When to change No. Parameter Default Description of the Italian value value the value programmer Minimum call number (filter on codes in transit It is required in building 1 Initial user Utente iniziale 99999999 from terminal 6 to terminal 1).
  • Page 32 Example of plate technical parameters Abbreviation on the display Minimum Maximum When to change No. Parameter Default Description of the Italian value value the value programmer Enables self-start of the video/audio door entry unit via commands F3, F4 and F5). Add to- Enables Abil.

  • Page 33: Integrating The Video Door Entry Unit With The By-Me System

    For the installation details see the diagrams in the following section. Standard video door entry unit diagrams. • Connection diagram with main video plate and indoor stations by Vimar. • Connection diagram for monitor pillar with distributor on the landing.

  • Page 34: Fast Guide To Using The Video Door Entry Unit

    Fast guide to using the video door entry unit Table of the functions of the buttons of the Vimar video door entry unit in Elvox Digibus systems. A distinction is made between cases when the monitor is OFF and when it is ON, that is whether it is on after an external call, from the plate or outside the door.

  • Page 35: Installation Rules And Compliance With Regulations

    Installation Regulations - Regulatory compliance - Glossary Installation Regulations. Installation should be carried out observing current installation regulations for electrical systems in the country where the products are installed. Regulatory compliance. EMC directive Standards EN 61000-6-1, EN 61000-6-3 Glossary Plate. Set of audio and video devices that permit identifying the person requesting access to the dwelling via the outdoor station.
  • Page 36 Viale Vicenza, 14 - 36063 Marostica VI Tel. +39.0424.488.600 - Fax: (Italia) 0424.488.188 907.1954A0.L.EN 01 0705 http://www.vimar.eu VIMAR - Marostica - Italy...
