The list can be navigated using the ƒ and „ keys. Use the left arrow to go to a newer signal
and the right one to go to an older one.
If the OK key is pressed while one signal is being displayed, extended info for that signal is
shown on the display:
By pressing OK again the previous view is recovered.
2. Search only the System Troubles.
System troubles are trouble signals generated by the receiver itself. The signals generated by
the VisorALARM PLUS 2U receiver always have the 00000000 account code that is reserved
and cannot be assigned to a mIP/IPDACT device.
The set of trouble signals that VisorALARM PLUS 2U can raise is described in the next table:
Trouble signal
Hdw failure: Fan 0
Hdw failure: Fan 1
Hdw failure: LCD
Hdw failure: Buzzer
Hdw failure: Printer
Network failure
Receiver is down
Primary is down
Backup is down
Storage full
Time is inaccurate
Signal DB overflowed
AC Loss
Low system battery
System Trouble signals are displayed by default like any other signal, but when the user
selects the extended info using the OK key the info shown includes a textual description of the
trouble as in the figure:
11/17/06 16:33:23
00001234 E110 01 001
Failure in the LCD device
Failure in the Local Piezo Sounder
The device specified in the monitor_ip_address
configuration parameter does not answer.
Probably the internet link is down
The receiver cannot receive signals
The Backup receiver has detected that the Primary
The Primary receiver has detected that the Backup
Received signals queue is full
The NTP server specified in the NTP configuration
The synchronization of the Primary and Backup
The stored signals database has been overwritten
AC loss has been detected through one of the
Low system battery has been detected through one
VisorALARM PLUS 2U Operating
III - 13
Description
Fan #0 has failed
Fan #1 has failed
Printer not detected
receiver is down
receiver is down
does not answer.
receivers can fail
inputs
of the inputs.
