- Page 1 VisorALARM PLUS 2U Operating Instructions Doc. DM375-I Rev. 1.0 May, 2007...
-
Page 2: Table Of Contents
ONTROLS AND NDICATORS 1.1. LCD Display ............................2 1.2. LED Indicators............................2 1.3. Keypad ..............................3 1.4. Local Piezo Sounder ...........................4 CHAPTER 3 OPERATING VISORALARM PLUS 2U ..................5 ..........................6 CCESSING THE RECEIVER ........................7 PERATING IN MANUAL MODE ....................9 PERATING WITH UTOMATION OFTWARE ........................10 ONITORING THE RECEIVER ......................12... -
Page 3: Chapter 1 System Overview
Chapter 1 System Overview... -
Page 4: The Visoralarm Plus 2U Receiver
If the automation software fails or isn’t present, VisorALARM PLUS 2U is able to acoustically signal the reception of new signals. It also provides specific function keys to manually acknowledge every received signal. -
Page 5: The Ip Modules (Mip/Ipdacts)
From this point on, the mIP/IPDACT will try to re-establish communications with both the main Teldat VisorALARM PLUS 2U as well as the backup, if there is one. As soon as this is re- established with either of the VisorALARM PLUS 2U, the mIP/IPDACT will intercept the telephone line once more. - Page 6 In order to maintain and update the registered mIP/IPDACTs base, the Teldat VisorALARM PLUS 2U has commands available to remotely update one or multiple configuration parameters used by the mIP/IPDACTs.
-
Page 7: Management And Monitoring
3. Management and Monitoring The IP VisorALARM PLUS 2U receiver can be managed and configured through a local console and also remotely (telnet). In both cases, the access is restricted to users who are identified by a user name and a password. Also the receiver can be monitored through a local console, remotely through telnet and from the receiver’s keypad and LCD display. -
Page 8: Chapter 2 Controls And Indicators
Chapter 2 Controls and Indicators... -
Page 9: Unit Controls And Indicators
VisorALARM PLUS 2U receiver control panel includes an LCD display, a keypad and several LED indicators. 1.1. LCD Display VisorALARM PLUS 2U uses a 40-character (2 lines of 20 characters each) high viewing angle LCD display. The display includes a long life white backlight that remains illuminated while system is PRIMARY VisorALARM Waiting for signals running. -
Page 10: Keypad
• key: This is used to go to the previous menu in the receiver menu tree. § § Enter key (OK) § Acknowledgement key The alpha-numeric keys are: § Keys labeled 0 to 9 § Key * § Key # VisorALARM PLUS 2U Controls and Indicators Doc.DM375-I Ver. 1.0 II - 3... -
Page 11: Local Piezo Sounder
A piezo sounder provides distinct audible indications for alarm, trouble and supervisory signals. Signal Sound Alarm Sounds continuously Supervisory Sounds on and off at a half of a second rate Trouble Sounds on and off at a second rate VisorALARM PLUS 2U Controls and Indicators Doc.DM375-I Ver. 1.0 II - 4... -
Page 12: Chapter 3 Operating Visoralarm Plus 2U
Chapter 3 Operating VisorALARM PLUS 2U... -
Page 13: Accessing The Receiver
Access to receiver keypad functions is password protected. If you are not logged into the VisorALARM PLUS 2U receiver, both when the ACK key is pressed twice or when the OK key is pressed to gain access to the receiver menus, a password is needed. The... -
Page 14: Operating In Manual Mode
PRIMARY VisorALARM 1 Signal pending If you are not logged into the VisorALARM PLUS 2U receiver when events are received pressing the ACK key for the first time will display the highest priority event and silence the receiver piezo. If the ACK key is pressed a second time you will be prompted for a password. - Page 15 When there are no more pending signals the receiver returns to its idle state displaying a status line indicating that it is waiting for new signals. PRIMARY VisorALARM Waiting for signals VisorALARM PLUS 2U Operating Doc.DM375-I Ver.1.0 III - 8...
-
Page 16: Operating With Automation Software
3. Operating with Automation Software When the VisorALARM PLUS 2U receiver operates with an Automation Software connected through the serial AUT port, the signals are automatically sent to the Automation Software for acknowledgement. Signals are also stored in the signal database for further review and the ACK and TRB LEDs still indicate alarm signals and trouble signals pending to restore. -
Page 17: Monitoring The Receiver
4. Monitoring the receiver The VisorALARM PLUS 2U receiver includes monitoring capabilities for the signal history log and account status that can be accessed and displayed through the keypad and the LCD display. A User Mode menu is displayed by pressing the OK key on the keypad. If this is the first time the User Mode menu has been accessed, the receiver prompts the user for a valid operator, supervisor or manager password. - Page 18 The “Account Status” option enters the “ACCOUNT STATUS” menu where the status and communication parameters for a specific mIP/IPDACT device can be monitored. This option is also fully described in next paragraphs. VisorALARM PLUS 2U Operating Doc.DM375-I Ver.1.0 III - 11...
-
Page 19: Accessing The Signal History Log
With this option the receiver does not apply any filters and displays all the stored signals beginning with the most recent. Each signal is displayed as in the next figure: 16:33:23 00001234 E110 01 001 Fire VisorALARM PLUS 2U Operating Doc.DM375-I Ver.1.0 III - 12... - Page 20 VisorALARM PLUS 2U receiver always have the 00000000 account code that is reserved and cannot be assigned to a mIP/IPDACT device. The set of trouble signals that VisorALARM PLUS 2U can raise is described in the next table: Trouble signal...
- Page 21 Restore signal (R qualifier) has not been received as yet. Signals stay in this list until the corresponding restore is received and the list is navigated as described in previous paragraphs. VisorALARM PLUS 2U Operating Doc.DM375-I Ver.1.0...
-
Page 22: Monitoring The Status Of An Account
6. Monitoring the status of an account The VisorALARM PLUS 2U receiver includes an option to display the communication status of a given account. This can be done through the “Account Status” option found in the receiver’s “USER MODE” menu. -
Page 23: Remote Ip Address
V4.1 EU Nov 06 2006 4. The “IP” option displays the mIP/IPDACT device IP address: Remote IP Address 60.78.34.89 5. The “Port” option displays the mIP/IPDACT device UDP port: Remote UDP Port 20300 VisorALARM PLUS 2U Operating Doc.DM375-I Ver.1.0 III - 16... - Page 24 NOTES: VisorALARM PLUS 2U Operating Doc.DM375-I Ver.1.0 III - 17...
