User Manual
English
Congratulations on the purchase of your
Leica DISTO™ D210XT.
The safety instructions and the user
manual should be read through
carefully before you use the
product for the first time. The
person responsible for the product must ensure that
all users understand these directions and adhere to
them.
Symbols used in this manual
The symbols used have the following meaning:
WARNING
Indicates a potentially hazardous situation or
an unintended use which, if not avoided, could result
in death or serious injury.
CAUTION:
Indicates a potentially hazardous situation or
an unintended use which, if not avoided, may result
in minor injury and/or in appreciable material, finan-
cial and environmental damage.
Important paragraphs which must be adhered
to in practice, as they enable the product to be used
in a technically correct and efficient manner.
Leica DISTO™ D210XT 776114
Intended Use
Permitted uses
Measuring distances
Computing functions, e.g. areas and volumes

Adverse uses

Using the instrument without instructions
Using outside the stated limits
Deactivation of safety systems and removal of
explanatory and hazard labels
Opening of the equipment by using tools
(screwdrivers etc.)
Carrying out modification or conversion of the
product
Use of accessories from other manufacturers
without the express approval of Leica Geosys-
tems.
Deliberate or irresponsible behaviour on scaf-
folding, when using ladders, when measuring
near machines which are running, or near parts of
machines or installations which are unprotected
Aiming directly into the sun
Deliberate dazzling of third parties; even in the
dark
Inadequate safeguards at the surveying site
(e.g when measuring on roads, construction
sites, etc.)
Symbols used in this manual
1
EN
D
N
S
FIN
DK
SLO
TR
GR
ROK
RUS
SK
CZ
H
PL
EST
LT
LV
BG
RO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DISTO D210XT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Leica DISTO D210XT

  • Page 1: Adverse Uses

    WARNING • Use of accessories from other manufacturers Indicates a potentially hazardous situation or without the express approval of Leica Geosys- an unintended use which, if not avoided, could result tems. in death or serious injury. • Deliberate or irresponsible behaviour on scaf-...
  • Page 2: Limits Of Use

    Also see section "Technical data". when in use.The person in charge of the product has The Leica DISTO™ is designed for use in areas perma- the following duties: nently habitable by humans, do not use the product •...
  • Page 3 PYTHAGORAS - key 10 Intermediate line 2 11 Intermediate line 1 REFERENCE - key 12 Main line HISTORICAL MEMORY/UNITS - key 13 Detailed display CLEAR/OFF - key 14 Ceiling area 15 Wall area 16 Circumference Leica DISTO™ D210XT 776114 Overview...
  • Page 4: Inserting / Replacing Batteries

    Precautions: To ensure the instrument remains watertight, Carry out periodic test measurements. you should avoid getting dirt on the battery compart- Particularly after the instrument has been subject to ment seals. Start up Leica DISTO™ D210XT 776114...
  • Page 5: Setting The Unit

    Setting the unit measurements. Press long until the desired unit is displayed. Make sure the Leica DISTO™ optic is kept clean and that there is no mechanical damage to the bumpers. Possible units: CAUTION:...
  • Page 6: Reference Setting

    The device automatically recognises the measurement position and adjusts the following measurement. Operation Leica DISTO™ D210XT 776114...
  • Page 7 Switching on continuous measurement (see above). the summary row, the individually measured values The corresponding maximum and minimum values are are displayed in intermediate lines 1 and 2. displayed. A long press on the key displays the perimeter Leica DISTO™ D210XT 776114 Measuring...
  • Page 8: Volume Function

    (e.g. height). The value is displayed in intermediate line 1. The calculated volume appears in the summary line, the last three measured values appear in interme- diate lines 1, 2, 3. Press the button for longer to display additional Functions Leica DISTO™ D210XT 776114...
  • Page 9 The result of the function is displayed in the summary measuring a distance, maximum or minimum contin- row. uous measuring is activated. If the button is pressed for along time while measuring a distance, maximum or minimum contin- uous measuring is activated. Leica DISTO™ D210XT 776114 Functions...
  • Page 10: Historical Memory

    Select measurement of measurement distance within the range of measurement Error Cause Correction Error Hardware error Should this message remain active after switching the instru- ment off and on several times, please contact your dealer. Appendix Leica DISTO™ D210XT 776114...
  • Page 11: Technical Specifications

    Laser type 635 nm, < 1 mW WARNING Protection against IP 65 The Leica DISTO™ conforms to the most strin- splashes and dust gent requirements of the relevant standards and Autom. power off: regulations. Laser after 60 s...
  • Page 12: Laser Classification

    Laser classification Precautions: The Leica DISTO™ produces a visible laser beam Do not stare into beam. Do not look into the laser which emerges from the front of the instrument. beam. Make sure the laser is aimed above or below eye level (particularly with fixed installations, in machines, etc.).
  • Page 13: Warranty

    Do not stare into the beam Laser class 2 Warranty acc. IEC 60825-1:2007 Maximum radiant power *: <1mW The Leica DISTO™ D210XT comes with a three* year Emitted wavelength: 620-690nm Beam divergence 0.16 x 0.6 mrad warranty from Leica Geosystems.
  • Page 14 Leica Geosystems dealer. All right reserved for changes (drawings, descriptions and technical specifications). Appendix Leica DISTO™ D210XT 776114...
  • Page 15 Leica Geosystems AG, Heerbrugg, Switzerland has been certified as being equipped with a quality system which meets the International Standards of Quality Management and Quality Systems (ISO standard 9001) and Environmental Management Systems (ISO standard 14001). Total Quality Management - Our commitment to total customer satisfaction. Ask your local Leica Geosystems agent for more information about our TQM program.
