ESIE05-03
Unit combination
FCQ140DV3B RZQ140B7W1B
FCQ71DV3Bx2 RZQ140B7W1B
FCQ71B7V3Bx2 RZQ140B7W1B
FCQ50B7V1x3 RZQ140B7W1B
FCQ35B7V1x4 RZQ140B7W1B
FFQ50B7V1Bx3 RZQ140B7W1B
FFQ35B7V1Bx4 RZQ140B7W1B
FBQ71B7V3Bx2 RZQ140B7W1B
FBQ50B7V1x3 RZQ140B7W1B
FBQ35B7V1x4 RZQ140B7W1B
FHQ71BUV1Bx2 RZQ140B7W1B
FHQ50BUV1Bx3 RZQ140B7W1B
FHQ35BUV1Bx4 RZQ140B7W1B
FHQ71BUV1Bx2 RZQ140B7W1B
FHQ71BUV1Bx2 RZQ140B7W1B
Symbols:
MCA: Min. Circuit Amps
TOCA: Total Over-current Amps
MFA: Max. Fuse Amps (see note 7)
MSC : Max. current during the starting compressor
RLA : Rated Load Amps
OFM : Outdoor Fan Motor
IFM : Indoor Fan Motor
FLA : Full Load Amps
kW : Fan Motor Rated Output
Notes: 1
2
3
4
5
6
7
Part 1 – System Outline
Power supply
50-400 14.2
50-400 14.1
50-400 14.7
50-400 14.7
50-400 15.9
50-400 15.6
50-400 15.9
Max.50Hz-440V
50-400 15.3
Min.50Hz-360V
50-400 15.6
50-400 15.5
50-400 14.7
50-400 15.3
50-400 15.9
50-400 14.1
50-400 14.9
RLA is based on the following conditions:
Power supply: 50Hz 230V
Indoor temp. - cooling: 27°C DB/19.0°C WB
Indoor temp. - heating: 20.0°C DB
Outdoor temp. - cooling: 35.0°C DB
Outdoor temp. - heating: 7.0°C DB/6.0°C WB
TOCA means the total value of each OC set.
Voltage range
Units are suitable for use on electrical systems where voltage
supplied to unit terminals is not below or above listed range limits.
Maximum allowable voltage variation between phases is 2%.
MCA represents maximum input current.
MFA represents capacity which may accept MCA. (Next lower standard fuse rating, minimum 15A)
Select wire size based on the larger value of MCA or TOCA.
MFA is used to select the circuit breaker and the ground fault circuit interruptor. (earth leakage circuit breaker)
Compressor
14.2 20 12.9 12.9
14.1 20 12.9 12.9
14.7 20 12.9 12.9
14.7 20 12.9 12.9
15.9 20 12.9 12.9
15.6 20 12.9 12.9
15.9 20 12.9 12.9
15.3 20 12.9 12.9
15.6 20 12.9 12.9
15.5 20 12.9 12.9
14.7 20 12.9 12.9
15.3 20 12.9 12.9
15.9 20 12.9 12.9
14.1 20 12.9 12.9
14.9 20 12.9 12.9
Specifications
OFM IFM
0.07+0.07 0.3+0.3 0.120 0.7
0.07+0.07 0.3+0.3 0.030x2 0.3x2
0.07+0.07 0.3+0.3 0.045x2 0.6x2
0.07+0.07 0.3+0.3 0.045x2 0.6x2
0.07+0.07 0.3+0.3 0.045x4 0.6x4
0.07+0.07 0.3+0.3 0.055x3 0.7x3
0.07+0.07 0.3+0.3 0.055x4 0.6x4
0.07+0.07 0.3+0.3 0.125x2 0.9x2
0.07+0.07 0.3+0.3 0.085x3 0.7x3
0.07+0.07 0.3+0.3 0.065x4 0.5x4
0.07+0.07 0.3+0.3 0.062x2 0.6x2
0.07+0.07 0.3+0.3 0.062x3 0.6x3
0.07+0.07 0.3+0.3 0.062x4 0.6x4
0.07+0.07 0.3+0.3 0.043x2 0.3x2
0.07+0.07 0.3+0.3 0.045x2 0.7x2
1–19
1
3
4
5
