MultiModem GPRS & CDMA Quick Start Guide
Attaching MultiModem to a Fixed Location
1. Typically, the MultiModem is mounted against a flat surface
with two mounting screws. Drill the mounting holes at the
desired location separated by 125mm (4 -15/16 inches)
center-to-center.
2. Slide the mounting brackets into the corresponding slots
on the back side of the MultiModem chassis.
3. Attach the MultiModem to the surface with two mounting
screws. Ensure the mounting screws have adequate
8
Scr ew Separ at i on
= 125 m m
15
or 4 i nches
16
M ount i ng Br acket
