Glow-worm swift flow 100e Installation Instructions Manual page 4

CE Mark
This boiler meets the requirements of Statutory
Instrument No. 3083 The Boiler (Efficiency)
Regulations, and therefore is deemed to meet the
requirements of Directive 92/42/EEC on the efficiency
requirements for new hot water boilers fired with liquid
or gaseous fuels.
Type test for purposes of Regulation 5 certified by:
Notified body 0087.
Product/production certified by:
Notified body 0087.
The CE mark on this appliance shows compliance with:
1. Directive 90/396/EEC on the approximation of the
laws of the Member States relating to appliances burning
gaseous fuels.
2. Directive 73/23/EEC on the harmonization of the
Laws of the Member States relating to the electrical
equipment designed for use within certain voltage limits.
3. Directive 89/336/EEC on the approximation of the
Laws of the Member States relating to
electromagnetic compatibility.
1.1 Installation
Materials and equipment should be fit for their purpose
and of suitable quality and workmanship.
1.2 Important Notice
This boiler is for use only on natural gas, G20.
TABLE 2
Lift Weight
Total Weight
Gas connection
Heating and return
Domestic hot water
Safety valve
Safety valve discharge
Water content
Expansion vessel capacity 8 litres (1.76 gallons)
Heating cold fill
pressure minimum
Ball valves are fitted in water and gas connections, plus a drain point on all water connections.
Boiler starts at an inlet pressure of 0.5bar but requires 0.8bar for maximum output.
For larger systems use an additional expansion vessel, see Section 4.
221141C
1 G e n e r a l
37.0kg (81.4lb)
50.4kg (111lb)
1 1
Rc / ( / in BSPT)
2 2
22mm compression
15mm compression
Preset 3bar (43.5lbf/in 2 )
15mm copper
1.74 litres (0.38 gallon)
0.7bar
2
(10.1lbf/in )
4
1.3 Sheet metal Parts
WARNING. When installing the appliance, care should
be taken to avoid any possibility of personal injury when
handling sheet metal parts.
1.4 Requirements
The installation of this boiler must be carried out by a
competent person in accordance the rules in force in the
countries of destination.
Manufacturer's instructions, supplied.
Manufacturer's instructions must not be taken as
overriding statutory requirements.
TABLE 1
C.H. Max D.H.W Max
NOMINAL kW
HEAT
INPUT(NETT) Btu/h
NOMINAL kW
HEAT
OUTPUT Btu/h
BURNER mbar
PRESSURE in.wg
APPROX. m 3 /h
3
GAS RATE ft /h
D.H.W
working pressure
Maximum Heating
system water
content using
fitted expansion
vessel.
Electrical supply
Electrical rating
Internal Fuse rating
MIN
20.21 36.2 11.63
68,953 123,500 39,678
17.6 29.3 9.1
60,000 100,000 31,000
6.2 15.5 1.8
2.6 6.2 0.7
2.1 3.4 1.2
75.8 121.8 43.4
0.5 to 10bar
2
(7.25 to 188lbf/in )
119 litres
(26.2 gallons)
with a cold
fill pressure
of 0.7bar
230V~50Hz
154W fused 3A
1) Type T2A
2) Type T630mA
