Appendix

Technical Specifications

Integrated DSP
Signal Processor
Maximum Calculation
Delay
Audio Latency
A/D and D/A Converters
Sample Rate
Control Inputs
Inputs (Control)
Analog Input Voltage Range
Digital Input Voltage Range
Control Outputs
Outputs (Control)
Output Voltage
Indicators and Controls
LED Status Indicators
Audio Signal Indication
Electrical Specifications
Mains Voltage
AC Power Consumption
Mains Connector
Power Dissipation
Physical
Dimensions
Net Weight
Operating Temperature
Cooling System
General
PC Configuration Software
Network Control
Communication Ports
Expansion Slots
Audio Channel Capacity
English
ESP-00 Series II
Four 32-bit floating-point digital signal processors, 200 MHz
6.4 GIPS/4.8 GFLOPS
288 s
860 μs (analog in to analog out)
24-bit
48 kHz
8 analog or digital inputs, 5.1 kΩ internal pull-up resistor to 5 V, 3.81 mm Euroblock, 9-pin
0 V to 3.3 V (maximum 5 V)
0 V to 3.3 V (threshold voltage = 1.6 V)
8 digital outputs, 10 kΩ internal pull-up resistor to 5 V, 3.81 mm Euroblock, 9-pin
High: 5 V @ 0.5 mA
Low: < 1 V @ 10 mA, open collector
Power, Status, Ethernet/Serial (RS-232 + CC-16)
Green (– 60 to – 21 dBFS), Yellow (– 20 to – 7 dBFS), Red (– 6 dBFS to Clip)
85 – 264V 50/60 Hz with PFC
< 35 VA typical / < 70 VA max at < 104 °F (40 °C) ambient
IEC 60320 – C14 (Inlet)
70 W (239 BTU, 60 kcal)
3.5" H x 19.0" W x 13.0" D (88 mm x 483 mm x 331 mm)
10.8 lb (4.9 kg)
32 °F – 104 °F (0 °C – 40 °C)
Internal fan
ControlSpace Designer software
® ™
Ethernet (RJ-45), 10Base-T
RS-232 (DB9M, DTE), Bose CC-16 (5.08 mm Euroblock 3-pin)
8 analog/digital audio, 2 GPIO (1 occupied)
64 (bi-directional, digital and/or analog)
