Available Accessories

Accessory Cards

The ControlSpace ESP-00 Series II processor has eight available audio expansion slots and supports up to 64 audio channels (up to
®
32 analog audio channels). 8 control inputs and 8 control outputs are supplied with the ESP-00 II processor and can be doubled to 16
inputs and 16 outputs by installing an optional GPIO Expansion card into the open GPIO 2 slot. Four DSP processors are employed and
cannot be expanded further in this model.
Figure 1. Open card slots, ESP-00 II processor, cover removed
Note: No audio cards are pre-installed in the ESP-00 II processor so the unit can be custom-configured to meet the needs of the
application. Please order accessory cards as needed for your application.
At time of print, the following expansion cards are available. For further information on these cards, and to view new cards that are
available, please visit pro.Bose.com.
• Dante network card
™
• CobraNet I/O expansion card
®
• ESPLink 8-Channel output card
• 4x4 mic/line input/output card series II
• SDR 4-Ch mic/line input card
• SDR 4-Ch line output card
• EDR line-level input card
• EDR line-level output card
• AES3 eight-channel input card
• AES3 eight-channel line output card
• Surround sound decoder input card
• GPIO Expansion card
English
8 available audio slots
(PC 359843-0020)
(PC 311506)
(PC 350513-0010)
(PC 041915)
(PC 041917)
(PC 041916)
(PC 041764)
(PC 041763)
(PC 041765)
(PC 041766)
(PC 302210)
(PC 041768)
1 available GPIO slot
Factory-installed DSP/Network/RS-232
and GPIO card
Installation Guide
