MultiModemBL User Guide
Fax Carrier Frequencies
All models:
Lease Line Restoral
All models:
Carrier Frequencies
2834 Series:
1932 Series:
1432 Series:
Carrier Frequencies - 2400 & 1200 bps (V.22bis/V.22 or Bell 212A Standard)
All models:
Carrier Frequencies - 300 bps (Bell Standard)
All models:
Carrier Frequencies - V.21
All models:
Carrier Frequencies - V.23
All models:
Transmit Level
All models:
Frequency Stability
All models:
14
V.21CH2 (Half Duplex)
1650Hz Mark, 1850Hz Space for Transmit Originate
1650Hz Mark, 1850Hz Space for Transmit Answer
V.27ter 1800Hz Originate/Answer
V.29 QAM 1700Hz Originate/Answer
V.17 TCM 1800Hz Originate/Answer
When in dial backup mode, modem attempts leased line restoral
periodically (controlled by S-Register S18 setting)
1800 Hz V.32/V.32bis/V.34/Enhanced V.34--33.6K/31.2K/28.8K/
26.4K/24K/21.6K/19.2K/16.8K/14.4K/12K/9.6K/7.2K/4.8K
1800 Hz V.32/V.32bis/V.32terbo/19.2K/16.8K/14.4K/12K/9.6K/7.2K/
4.8K
1800 Hz V.32/V.32bis/14.4K/12K/9.6K/7.2K/4.8K
Transmit Originate: 1200 Hz
Transmit Answer: 2400 Hz
Receive Originate: 2400 Hz
Receive Answer: 1200 Hz
1270 Hz Mark, 1070 Hz Space for Transmit Originate
2225 Hz Mark, 2025 Hz Space for Receive Originate
2225 Hz Mark, 2025 Hz Space for Transmit Answer
1270 Hz Mark, 1070 Hz Space for Receive Answer
980 Hz Mark, 1180 Hz Space for Transmit Originate
1650 Hz Mark, 1850 Hz Space for Transmit Answer
650 Hz Mark, 1850 Hz Space for Receive Originate
980 Hz Mark, 1180 Hz Space for Receive Answer
390 Hz Mark, 450 Hz Space for Transmit Originate
1300 Hz Mark, 2100 Hz Space for Transmit Answer
1300 Hz Mark, 2100 Hz Space for Receive Originate
390 Hz Mark, 450 Hz Space for Receive Answer
-11dBm (dial-up), -9 or -15 dBm (leased-line); dBm level selectable
with DIP-Switch #3 in leased line setting; -10dBm (dial-up)*, -13 dBm
(leased-line)*
*BLK models Only
±0.01%
