Onkyo CR-305TX Service Manual

SERVICE MANUAL
CD RECEIVER
CR-305TX
MODEL
STANDBY/ON MEMORY FM MODE DISPLAY
CLEAR
PHONES
Silver model
UDD,UDT
UGT,UGR,
UPP
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
TUNING/PRESET
INPUT
120V AC, 60Hz
220-230V AC, 50Hz
230-240V AC, 50Hz
ON THE
CR-305TX
Ref. No. 3723
062002
REMOTE CONTROLLER
STANDBY/ON INPUT
TIMER ENTER
RANDOM
CD
MEMORY REPEAT
SCROLL
MD
PLAY MODE REPEAT
SLEEP A.PRESENCE
VOLUME
CLOCK
CALL MUTING
CDR
PLAY MODE REPEAT
TAPE
TUNER
PRESET
RC-421S
RC-421S
